Kinematics and Dynamics Simulation of L-10/7 Piston Type Air Compressor with Double Actions

Abstract:

The virtually assemble model of the L-10/7 piston type air compressor with double actions was established under SolidWorks software. The kinematics and dynamics simulation of compressor’s crank-link mechanism were done by SolidWorks Motion, and the main results of simulation were given out, the results coincide with the date of design calculate. It can be used as the foundation for stress calculation and optimization design of the air compressor.
