The Transmission Design and Production of Cylindrical Cam and Gear Joint Transmission Reducer

Abstract:

Design a kind of reducer, the first stage transmission is a cylindrical cam, the secondary stage transmission is a gear transmission. Multistage transmission of the reducer has carried on the design calculation and checking. On the basis of the lateral cylindrical cam lateral transmission mathematical model, conducted the spiral curve analysis and calculation with numerical analysis software MATLAB. Import the spiral curve data into SOLIDWORKS to complete the 3D modeling of cylindrical cam. According to the structural design of cylindrical cam, complete reducer machine design and virtual assembly of gearless reducer. The stress analysis was carried out on the cam disk with the ANSYS Mechanical Analysis Module of SOLIDWORKS, designed to meet the working conditions. Conducted physical development based on CAD and CAE. The result showed that the design was fast and effective, significantly shorten the production cycle.

• Periodical: Applied Mechanics and Materials (Volume 684)
• Pages: 323-329
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.684.323
• Online since: October 2014
• Authors: Ming Wang Dong, Ting Ting Yang, Lin Wu*
• Keywords: Cylindrical Cam, Multistage Transmission, Physical Development, Stress Analysis

References

[1] Wang Vobo, Cao Jujiang, Jiao Nan. Reverse Design of General Harmonic Trapezoidal Cam Curve Based on Optimization Method. [J] Journal of Mechanical Transmission, 2014, 38(2): 83-85.

[2] DONG Mingwang, WU Lin, etc. Research and Trial Production of Gearless Reducer [J]. Journal of Wuhan University of Technology (Treansportation Science & Engineering), 2014, 38(1): 35-39.

[3] Dong Mingwang, Wu Lin, etc. Research on Cylindrical Cam Lateral Transmission Mechanism Profile [J]. China Mechanical Engineering, 2014, 25(3): 337-340.

[4] Dong Mingwang, Wu Lin, etc. Single Stage Lateral Transmission Cylindrical Cam Reducer [P]. China Patent: ZL201320537675. 0, 2014-04-09.

[5] He Wei, Cao Jujiang, Yang Fulian, ect. Review of Research of cam Mechanisms China [J]. Chinese Journal of Mechanical. 2005, 41(6): 1-4.

[6] Lin Wu, Mingwang Dong. Research on Transmission Principle of Gearless Reducer [C]. Energy Development. Trans Tech Publications Ltd 2014, Vols. 860-863, pp: 1744-1747.

DOI: 10.4028/www.scientific.net/amr.860-863.1744

[7] Chang Yong, Yang Fufu, Hu Zhichao, etc. Research on the General Second Mechanisms Synthesis Task of Disc Cam Mechanisms with Roller Follower Moving in General Planar Motion [J]. Chinese Journal of Mechanical. 2012, 48(15): 47-57.

DOI: 10.3901/jme.2012.15.047

[8] Liu Mingtao, Chen Gang, Li Yanqi, etc. Research on Force Condition of Inner Parallel Indexing Cam Mechanism [J]. Journal of Machine Design, 2014, 31(4): 46-48.

[9] Zhang San, Zhang Guoqing. Dynamic Contact Analysis for Globoidal Indexing Cam Mechanism [J]. Journal of Machine Design, 2014, 31(2): 35-39.
