The Mechanics Analysis of the Perforated Casing on Reservoir Sanding Finite Tunneling Section

Abstract:

Perforated casing eyehole stress concentration and sanding and compaction are the main reasons of casing abnormal damage during the exploitation. To understand the impact of reservoir sanding on perforated casing strength, fracture mechanics is applied to analyze the stress concentration of casing caused by perforating, while rock mechanics is applied to analyze the load of perforated casing of reservoir sanding limited bailed section, and on this basis, the impact of reservoir sanding on perforated casing strength is analyzed by the three-dimensional finite element model building. The analysis results show that the finite element solution and the theoretical solution of stresses of the perforated casing of reservoir sanding limited bailed section can be verified with each other. Under the same condition, the theoretical solution is bigger than the finite element solution, this is mainly due to the perforated casing additional bending stress effect is considered in the fracture mechanics theoretical analysis. It is conservative to estimate the perforated casing safety by finite element solution, while the theoretical solution is economical.

• Periodical: Applied Mechanics and Materials (Volume 684)
• Pages: 83-87
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.684.83
• Online since: October 2014
• Authors: Huan Huan Pan, Yi Hua Dou, Yin Ping Cao*
• Keywords: Finite Element Analysis (FEA), Perforated Casing, Sanding, Strength Theory

References

[1] Ruzhong Tang, Tongtao Wang and Xiangzhen Yan: Finite element analysis of the effect of perforating parameters on casing strength (2010) , (in chinese).

[2] Bo Tang, Zhanghua Lian and Gan Liu: Theory analysis of perforated casing collapsing(2004) , (in chinese).

[3] Huawei Yu, Maohua Li and Weidong Niu: Sand production rate on the mechanical performance of perforated casing analysis and calculation(2009) , (in chinese).

[4] Shaokai Tong, Xiaohang Xu and Qi Feng: The fracture mechanics analysis of the the perforated casing in high temperature and high pressure deep well(2013) , (in chinese).

[5] Zhilun Xu: Elastic mechanics(2006).

[6] Hongwen Liu: Mechanics of materials(2004).

[7] Qingyu Hou, Bin Chen and Huanhuan Pan: the strength of perforated casing influenced by sanding , production pressure differential and transformation pressure(2014) , (in chinese).

[8] Hongshan Zhao and Zhichuan Guan: Mechanics analysis of casing damage caused by sand production rate (2006), (in chinese).

[9] Wei Chen, Xiujuan Yang and Xing Yan: The intensity decreasing ratio analysis and parameter optimal design of the perforation casing(2014) , (in chinese).
