LES of Airflow Distribution for CRH₂ Electric Motor Train Units

Abstract:

In the premise of parallel computing, large eddy simulation (LES) model was adopted to set up math formers for the characteristics of airflow origination in CRH₂ Electric Motor Train Units(EMU) in this paper. The Smagorinsky-Lilly dynamic sub-grid model was adopted for fitting local turbulent structure and confirming benchmark model coefficient. Amended balance layer model was used to the wall functions. The temperature and velocity fields in the compartments were numerically simulated. Furthermore, area discretization adopted finite volume method. The results showed, adopting the method of enlarging calculation region, the instantaneous and continuity of turbulence were reflected truly and accurately. The analysis provided a reference for LES of airflow organization in high-speed train. It was also a new reference for the evaluation of comfort environment in the train.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 109-112
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.109
• Online since: November 2014
• Authors: Zhong Zan Wang, Zhao Hui Qi, Hui Tian
• Keywords: Airflow Distribution, CRH₂ Electric Motor Train Units, Large Eddy Simulation (LES), Parallel Computing, Turbulent Organization

References

[1] Zhang Zhaoshun, Cui Guixiang, Xu Chunxiao: Theory and Application of Turbulence Large Eddy Numerical Simulation, Beijing, Tsinghua University Press(2008), pp.97-129.

[2] Xu Yunwu, Deng Xiaojun, Yan Guizhen, Deng Xueshou: CRH2 200km/h Multiple Units, Electric Drive For Locomotives, No. 3(2007), pp.39-46.

[3] Luo Chunxiao: Focus on Speed-up Campaign- CRH2, Railway Knowledge, No. 2(2007), pp.12-13 RANS, Greyden Press: Columbus, Advance in DNS/LES(1997), p.137.

[4] International Union of Railwaya UIC553-2004, Heating, Ventilation and Air Conditioning in Coaches 90-1-1, 5th Edition , Beijing, Railway Quality Control(2004), pp.13-23.

[5] Grotzbach: Direct Numerical and Large Eddy Simulation of Turbulent Channel Flows. Encyclopedia of Fluid Mechanics West Orange(1987), pp.1337-1391.
