Inverse Design and Numerical Control Processing of the Little Bear Punch

Abstract:

Inverse design is the process of using a certain means of measurement to measure entity or model, and according to the measurements, refactoring physical CAD model through Three-dimensional geometric modeling methods. Basing on the little model, use reverse engineering methods, three-dimensional scanning technology and Raindrop Company produced the inverse engineering software to finish the reverse three-dimensional modeling design of little bear punch. Applying Master CAM to set parameters, simulation run, and automatically generate NC code, in the vertical machining center, complex curved surface NC machining of the model can be finished. In engineering practice, it can improve work efficiency, reduce the labor intensity of product development, and reduce the artificial error of the design.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 113-116
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.113
• Online since: November 2014
• Authors: Ge Zheng*, Chun Wang, Bo Huang
• Keywords: Geomagic Studio, Inverse Design, Master CAM, NC Machining, Three-Dimensional Scanning

References

[1] SiYuan Cheng. Surfacing Reconstruction Based on Geomagic Studio Software and Application Example [J]. Modern Manufacturing Engineering, 2011(1): 8-12. (In Chinese).

[2] ManCai He. Die Design and Processing of -Mastercam X Detailed Examples [I]. Beijing: People's Posts and Telecommunications Press. (In Chinese).

[3] Yan Shan, BinFei Xie. Imageware Reverse Modeling Technology Base [M]. Beijing: Tsinghua University Press, 2006. (In Chinese).

[4] Jiyuan Zhang, Xintao Ge. Inverse design on disk shaped cam mechanism with swinging oblique bottomed follower[J]. Journal of Machine Design, 2007, 24(4): 16-18(In Chinese).

[5] Liu Yang, Chen Xi, Shi Geya, Wang jing. The Application of Reverse Engineering Teehnology Based on Imageware[J]. Modular Machine Tool & Automatic Manufacturing Technique, 2012, (1): 51-54(In Chinese).
