The Work Course Simulation of Electromagnetic Coil Vertical Launcher for Missile

Abstract:

Through putting forward one kind of magnet coil launcher model of new structure; expound the basic component and the work principle of this launcher, built the mathematical model of this launcher work course. Through the dynamic simulation for its work progress, we get the electromagnetism that current and launch package are received power, speed and displacement etc. Comparatively analyzing the influence through changing system stored energy and to the system operating and the progression of launch coil. The result indicates: launching the coil possesses the better acceleration capability than the drive coil; Launching the speed of package energetically has the influence to electromagnetism, and along with the increase of speed, launches the electromagnetism that the package is received energetically reducing more greatly; Suitable change system stored energy can realize the vertical launch of missile with progression that launches the coil.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 3324-3327
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.3324
• Online since: November 2014
• Authors: Wei Bo Li*, Qi Lai Huang, Xiao Yong Chang, Jian Yi Zhou
• Keywords: Electromagnetic Coil Vertical Launch, Launcher Component, Mathematical Models

References

[1] H. Kolm, P. Mongeau. Basic principles of coaxial launch technology [J]. IEEE Transactions on Magnetics, 1984, 20(1): 227-230.

DOI: 10.1109/tmag.1984.1063050

[2] K. MacKinney, P. Mongeau. Multiple stage pulsed induction acceleration [J]. IEEE Transactions on Magnetics, 1984, 20(1): 239-242.

DOI: 10.1109/tmag.1984.1063089

[3] D. G. Elliott. Traveling wave induction launchers [J]. IEEE Transactions on Magnetics, 1989, 25(1): 159-163.

DOI: 10.1109/20.22526

[4] Wang Ying, Xiao Feng. Theory of electric gun[M]. Beijing: National Defense Industry Press, 1995：94-95.

[5] Wang Ying, Leiyinchao. Counts in axial symmetry coil magnetic field [M]．Beijing: measure publishing house, 1991：209-213.

[6] Lei Yinzhao．Calculation of axisymmetric magnetic field of coil [M]．Beijing：Publishing House of Chinese Measurement，1991：209～213.

[7] A. Y. Wu. Parameter studies for traveling wave coaxial launchers[J]．IEEE Transactions on Magnetic，1991，27(1)：617-622.

DOI: 10.1109/20.101105
