Dynamic Balancing of the Threshing Drum in Combine Harvesters – The Process, Sources of Imbalance and Negative Impact of Mechanical Vibrations

Abstract:

The purpose of this article is to present the description of the process of the dynamic balancing of threshing drum in combine harvesters as well as the sources of imbalance. The dynamic balancing analysis was carried out in production facility on dynamic balancing machine. Dynamic balancing of slats of the combine harvester threshing drum was determined by reference to the specified mass dynamic unbalance. The article also presents the influence of unbalanced machine elements on the human body.

• Periodical: Applied Mechanics and Materials (Volume 693)
• Pages: 424-429
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.693.424
• Online since: December 2014
• Authors: Jolanta B. Krolczyk*, Stanisław Legutko, Grzegorz M. Krolczyk
• Keywords: Calibrating Mass, Combine Harvester, Dynamic Imbalance, Mechanical Vibrations, Threshing Drum

References

[1] S. Erkaya, Investigation of balancing problem for a planar mechanism using genetic algorithm, Journal of Mechanical Science and Technology. 27 (2013) 2153–2160.

DOI: 10.1007/s12206-013-0530-z

[2] G.M. Krolczyk, J.B. Krolczyk, S. Legutko, A. Hunjet, Effect of the disc processing technology on the vibration level of the chipper during operations, Tehnički Vjesnik - Technical Gazette. 21 (2014) 447 – 450.

[3] V.I. Zhiganov, Y.N. Sankin, Improving precision lathes by dynamic balancing, Russian Engineering Research. 31 (2011) 785–787.

DOI: 10.3103/s1068798x11080260

[4] G.M. Krolczyk, P. Nieslony, S. Legutko, Determination of tool life and research wear during duplex stainless steel turning, Archives of Civil and Mechanical Engineering. (2014), http: /dx. doi. org/10. 1016/j. acme. 2014. 05. 001.

DOI: 10.1016/j.acme.2014.05.001

[5] J. Sill, B. Ayalew, A saturation-balancing control method for enhancing dynamic vehicle stability, International Journal of Vehicle Design. 61 (2013) 47-66.

DOI: 10.1504/ijvd.2013.050839

[6] P. Zagajski, K.A. Dreszer, Factors determining energy consumption of grain threshing (in Polish), Inżynieria Rolnicza. 9 (97) (2007) 279-288.

[7] G. Basista, B. Cieślikowski, J. Kaczorowski, Detection of threshing drum deformations in combine harvesters based on imbalance signal (in Polish) Inżynieria Rolnicza. 2 (35) (2002) 7-14.

[8] G. Basista, B. Cieślikowski, Influence of true contour of beater slat of threshing drum on change of threshing gap (in Polish), Acta Agrophysica. 2 (1) (2003), 15-20.

[9] M.A. Książek, Modelling and optimization of the system man - vibration isolator - machine (in Polish), Monografia 244, Wydawnictwo Politechniki Krakowskiej, Kraków, (1999).

[10] Factsheet 99, Safe maintenance in agriculture, European Agency for Safety and Health at Work (2011).

[11] Z. Serwański, Work safely guide for farmers (in Polish), Państwowa Inspekcja Pracy. (2009).

[12] T. Liu, F. Gao, X. Zhao, C. Qi, Static balancing of a spatial six-degree-of-freedom decoupling parallel mechanism, Journal of Mechanical Science and Technology. 28 (2014) 191–199.

DOI: 10.1007/s12206-013-1104-9

[13] J. Sopanen, J. Heikkinen, A. Mikkola, Experimental verification of a dynamic model of a tube roll in terms of subcritical superharmonic vibrations, Mechanism and Machine Theory. 64 (2013) 53–66.

DOI: 10.1016/j.mechmachtheory.2013.01.009

[14] F. Sève, M.A. Andrianoely, A. Berlioz, R. Dufour, M. Charreyron, Balancing of machinery with a flexible variable-speed rotor, Journal of Sound and Vibration. 264 (2003) 287–302.

DOI: 10.1016/s0022-460x(02)01173-2
