Theory Analysis of Full-Scale Segment Model of Huaian Cable-Stayed Bridge Pylon

Abstract:

The difference of the mechanical performance between the whole bridge pylon and the segment model are analyzed in theoretical method to provide theoretical support for the full-scale segmental model test study. Firstly, choose the most representative full-scale segment in anchorage zone of bridge pylon. Secondly, select the whole model composed of several segments. Finally, analysis the stress distributions in two models under the working load and the cracking load. In the coordinate segment position, stress distribution under design cable force in whole model and full scale segment model is almost the same. It indicates that the working performance of the anchorage zone in the bridge pylon can be studied through the full-scale segment model test.

• Periodical: Applied Mechanics and Materials (Volumes 71-78)
• Pages: 4614-4618
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.71-78.4614
• Online since: July 2011
• Authors: Hong Yuan Tang, Zhe Lin Fan
• Keywords: Bridge Pylon, Cable-Stayed Bridge, Full-Scale Model

References

[1] Zhi Liu: Segmental experiment study on prestressed concrete pylon of RunYang cable-stayed bridge. (Master degree thesis of Southeast University, Nanjing 2003), in Chinese.

[2] Sitian Liu: Journal of China & Foreign Highway, 2 (2004), pp.36-41, in Chinese.

[3] Hongyuan Tang: Study on key problems of cable-stayed bridge PC pylon. (Doctor degree thesis of Southeast University, Nanjing 2005), in Chinese.

[4] Zhao Liu, Shaoping Meng, Zhitao Lv: Journal of Chinese Engineering Science, 12 (2003), pp.48-54, in Chinese.
