Curve Cutting ZrO₂ Ceramic and Cooling Lower Surface Cutting Silicon Wafer with Laser Induced Thermal-Crack Propagation

Abstract:

In laser induced thermal crack propagation (LITP) cutting brittle materials, according to the laser absorption ability, materials are divided into the body absorption and surface absorption. This paper indicates the fracture mechanism of LITP cutting surface absorption brittle materials. The crack extension appears in the lower surface firstly in this stress distribution state, then the crack extends to the upper surface and the laser scanning direction with the LITP cutting. The stress field of cutting ZrO₂ ceramic is studied by finite element software ANSYS. The crack propagation process of cutting silicon wafer is studied by finite element software ABAQUS. According to the fracture mechanism, the curve cutting the ZrO₂ ceramic experiments and the cooling lower surface cutting the silicon wafer experiments are carried out in this paper. Optical microscope and laser scan confocal microscope (LSCM) photographs of the curve path the ZrO₂ ceramic and separation surface cutting the silicon wafer are obtained to examine the cutting quality. The quality of the curve path is very good. The quality of the separation surface in cutting the silicon wafer with the cooling lower surface is better than conventional environment.

You might also be interested in these eBooks

Mechanical Engineering, Materials Science and Civil Engineering III

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 711)

Pages:

222-226

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.711.222

Citation:

Cite this paper

Online since:

December 2014

Authors:

Chun Yang Zhao, Hong Zhi Zhang, Li Jun Yang, Yang Wang*

Keywords:

Brittle Materials, Cooling Lower Surface, Curve Cutting, Fracture Mechanism, Laser Induced Thermal Crack Propagation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] L.J. Yang, Y. Wang, Z.G. Tian, N. Cai, YAG laser cutting soda-lime glass with controlled fracture and volumetric heat absorption, Int. J. Mach. Tool. Manu. 50 (2010) 849–859.

DOI: 10.1016/j.ijmachtools.2010.07.001

Google Scholar

[2] C.Y. Zhao, H.Z. Zhang and Y. Wang, Semiconductor laser asymmetry cutting glass with laser induced thermal-crack propagation, Optics and Lasers in Engineering, 63 (2014) 43–52.

DOI: 10.1016/j.optlaseng.2014.06.008

Google Scholar

[3] Ch.H. Tsai, Fracture Mechanism of Laser Cutting With Controlled Fracture, Journal of Manufacturing Science and Engineering, 125 (2003) 519-528.

DOI: 10.1115/1.1559163

Google Scholar

[4] Ch.H. Tsai, Ch.H. Ou, Machining a smooth surface of ceramic material by laser fracture machining technique, J. Materials Processing Technology, 155-156 (2004) 1797-1804.

DOI: 10.1016/j.jmatprotec.2004.04.363

Google Scholar

[5] Ch.H. Tsai, H.W. Chen, Laser cutting of thick ceramic substrates by controlled fracture technique, J. Materials Processing Technology, 136 (2003) 166-173.

DOI: 10.1016/s0924-0136(03)00134-1

Google Scholar

[6] J. Liu, J. Lu, Thermal stress cleaving of silicon wafer by pulsed Nd: YAG laser, J. Chinese Optics Letters. 8(2010)1000-1003.

Google Scholar

[7] L.J. Yang, Y. Wang, Z.G. Tian, Laser Cutting ZrO2 Ceramic with Controlled Fracture Technique, International Conference on Mechatronics and Automation. (2012).

Google Scholar

[8] C.Y. Zhao, H.Z. Zhang, Y. Wang, Research On Laser Induced Thermal-Crack Propagation Cutting Silicon Wafer, Advanced Materials Research. 628 (2013) 211-216.

DOI: 10.4028/www.scientific.net/amr.628.211

Google Scholar
