Research on Underwater Static Electric Field for Warship Based on Hybrid Model

Abstract:

A new method that is to model the electric field of a warship with a hybrid model which is “horizontal current line plus discrete dipoles” is put forward. The majority of the electric field is simulated by horizontal current line, and several discrete dipoles can be used to modify the detail of the electric field. This method is expected to have same precision but more stabilization and less calculation. The method is validated by experiments using a physical scale model of ship.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 925-929
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.925
• Online since: January 2015
• Authors: Qiang Bian*, De Hong Liu, Xiang Jun Wang
• Keywords: Anticorrosion Design, Catholic Protection, Discrete Electric Dipoles, Horizontal Current Line, Hybrid Model, Static Electric Field

References

[1] LU Xin-cheng，GONG Shen-guang，ZHOU Jun，et al．The electromagnetic field of a time-harmonic HED embedded in an n-layer conducting half-space[ C]．Asia-Pacific Conference on Environmental Electromagnetics CEEM'2003，173 - 177.

DOI: 10.1109/ceem.2003.237820

[2] Li K，Park S O．Electromagnetic field in the air generated by a horizontal electric dipole located in the spherical electrically earth coated with a dielectric layer [J]．J．of electromagnetic waves and Appl．，2003，17(10)：1399-1417.

DOI: 10.1163/156939303322519586

[3] Demilier L，Durand C，Rannou C，et al．Corrosion related electromagnetic signatures measurements and modelling on a 1：40th scaled model [J]．Simulation of Electro -chemical Processes II．Engineering Sciences volume , 2007，54：368.

DOI: 10.2495/ecor070231

[4] Adey R，Baynham J．Predicting corrosion related electrical and magnetic fields using BEM [C]．Conf．Proc．UDT Europe，2000：473-475.

[5] Davidson S J，Rawlins P G．Characterisation of the seabed conductivity environment in littoral waters for electromagnetic signature analysis [C]．Conf．Proc．UDT Europe，2000：384-391.

[6] Jianhua W，Guangzhou L，Yongsheng L．Simulation and measurements of extra low frequency electromagnetic field [C]．Conf．Proc．UDT Europe，2004.

[7] Adey R，Baynham J M W．Predicting corrosion related signatures．Simulation of Electrochemical Processes II [J]．Engineering Sciences，2007，54：368-371.

[8] Dymarkowski K，Uczciwek J．Ships detection based on measurement of electric field in disturbance existing region [C]．Conf．Proc．UDT Europe，2000：554-560.

[9] ChenHuan. The Study of High-Resolution Location Identification Method for The Linear Array Submarine Noise Source[D]. Harbin Engineering University，2011，1-8.

[10] BaoZhonghua，GongShenguang，SunJianying. Location of horizontal electric dipole source embedded in deep sea by using two vector-sensor[J]. Journal of Naval University of Engineering，2011，23(3)：53-58.
