Based on a Microcontroller the Real-Time Control System Design of Manipulator of Multiple Degrees of Freedom

Abstract:

Manipulator of multiple degrees of freedom has been widely used in all kinds of rescue and exploring robots. This paper regard a kind of 6 DOF manipulator controller as the design object.The data acquisition for WDD35D4 sensors is carried by the C8051F020 microcontroller and sent through a wireless transmitter NRF905 after encrypted.Then the wireless transmitter NRF905 of the manipulator receives decryption. Through data processing and the steering gear adjustment, the angle of linear potentiometer corresponds to the angle of steering by 1-1. Then it drives the manipulator to work out and simulate the same motion of mechanical arm controller, and make real-time synchronization control.
