Automation Control System of the Pressure Pulse Testing Rig

Abstract:

With the development of industrial automation, people are increasingly demanding high product quality. Especially in automotive and aerospace fields, the fatigue quality of components determines the merits of the whole vehicle. Therefore fatigue performance testing has good prospects. Pressure pulse testing rig is a automatic control system. The system uses the solution which combines the virtual instrument technology with PLC controller technology. It has the ability to get the function of signal acquisition, signal analyzing, data processing and automatic control together. It enables the system to run automatically in accordance with setting commands and avoids the problem that the CNC system lacks of real-time capability and the disadvantage that the whole PLC driver control system can not meet the requirement of data acquisition and data processing. At the same time, it has both the advantages in the open CNC system and advantages in the controller system and can realize the highly efficient control.

• Periodical: Applied Mechanics and Materials (Volume 734)
• Pages: 153-156
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.734.153
• Online since: February 2015
• Authors: Zhi Hui Zhu, Yu Jie Gong, Xin Fu Liu*
• Keywords: Automatic Control Theory, LabVIEW, PID, PLC

References

[1] Mengwen Zhao: submitted to Hydraulic and pneumatic (2009). In Chinese.

[2] M. Ruiz and E. Barrear: submitted to Fusion Engineering and Design (2004).

[3] Zhenfeng Ma, Xianli Liu and Peng Wang: submitted to Journal Harbin Univ. Research (2005). In Chinese.

[4] Hongliang Li: submitted to Application Research of Computer (2003). In Chinese.

[5] Information on http: /www. fa. omron. com. cn.

[6] Yu Zhu, Tibo Zhao: submitted to Machine Tool & Hydraulics (2009). In Chinese.

[7] Xiaobing Zhou, China Patent CN203658183U. (2014).

[8] Dongning Chen: submitted to Hydraulic and pneumatic (2013). In Chinese.
