Review and Outlook of HTS Cable Research

Abstract:

High-Temperature Superconducting (HTS) cable has the merits of high capacity, low line loss, narrow corridor, and environmental friendly, which has bright prospects for current tendency of accelerating development of renewable energy, shortage of available land, and awakening of environmental awareness. In the past decades, HTS cable technology made remarkable progress. Based on the past and current situation, the paper introduces the HTS materials for cable and presents the structures, classification, heat losses, and cryogenic method of HTS cable. Overview of HTS cable research in typical country is stated and representative HTS cable projects are listed. In the end, application outlook and development tendency of HTS cable in the future are made.

• Periodical: Applied Mechanics and Materials (Volume 734)
• Pages: 720-725
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.734.720
• Online since: February 2015
• Authors: Bao Qun Zhang, Rui Shi, Zhong Jun Chi, Cheng Gong, Ran Jiao, Long Fei Ma, Yan Xia Chen
• Keywords: Application Outlook, Development Status, HTS Cable, Review

References

[1] Beales T P, Friend C M, Segir W, et al. A dc transmission cable prototype using high-temperature superconductors[J]. Superconductor Science & Technology, 1996, 9(1): 43-47.

DOI: 10.1088/0953-2048/9/1/006

[2] Lindsay D T, Ieee, Ieee. Operating experience of the Southwire high temperature superconducting cable installation [M]. New York: Ieee, (2002).

DOI: 10.1109/pesw.2002.984974

[3] Nakashima T, Kobayashi S, Kagiyama T, et al. Overview of the recent performance of DI-BSCCO wire[J]. Cryogenics, 2012, 52(12): 713-718.

DOI: 10.1016/j.cryogenics.2012.06.018

[4] Rupich M W, Li X P, Sathyamurthy S, et al. Second Generation Wire Development at AMSC[J]. IEEE Transactions on Applied Superconductivity, 2013, 23(3): 5.

DOI: 10.1109/tasc.2012.2235495

[5] Maruyama O, Ohkuma T, Masuda T, et al. Development of 66 kV and 275 kV Class REBCO HTS Power Cables[J]. Applied Superconductivity, IEEE Transactions on, 2013, 23(3): 5401405-5401405.

DOI: 10.1109/tasc.2012.2235497

[6] Ohmatsu K, Muranaka K, Fujino K, et al. Design study of model cable conductor by using HoBCO thin film tape[J]. IEEE Transactions on Applied Superconductivity, 2004, 14(2).

DOI: 10.1109/tasc.2004.830002

[7] Demko J A, Sauers I, James D R, et al. Triaxial HTS cable for the AEP bixby project[J]. IEEE Transactions on Applied Superconductivity, 2007, 17(2): 2047-(2050).

DOI: 10.1109/tasc.2007.897842

[8] Maguire J F, Schmidt F, Bratt S, et al. Installation and Testing Results of Long Island Transmission Level HTS Cable[J]. IEEE Transactions on Applied Superconductivity, 2009, 19(3): 1692-1697.

DOI: 10.1109/tasc.2009.2018221

[9] Wang Bang-zhu, Dai shao-tao，Zhang Dong, et al. Analysis of heat losses of warm dielectric HTS DC long cable [J]. Cryogenics and Superconductivity, 2013, 41(11): 1-4.

[10] Chiyoda. Experimental Research for High-temperature Superconductive Direct-current Transmission System[J]. June 17 Press Release, 2013: 1-2.

[11] Sytnikov V E, Bemert S E, Ivanov Y V, et al. HTS DC Cable Line Project: On-Going Activities in Russia[J]. IEEE Transactions on Applied Superconductivity, 2013, 23(3).

DOI: 10.1109/tasc.2013.2245280

[12] Won Y J, Kim J G, Kim A R, et al. Power system analysis of Hanlim superconducting HVDC system using real time digital simulator[J]. Physica C: Superconductivity, 2011, 471(21–22): 1290-1294.

DOI: 10.1016/j.physc.2011.05.180

[13] Geschiere A, Melnik I, Willen D, et al. Breakthrough in development of superconducting cables [M]. 21st international conference on electrical distribution. (2011).

[14] Tomita M, Muralidhar M, Suzuki K, et al. Development of 10 kA high temperature superconducting power cable for railway systems[J]. Journal of Applied Physics, 2012, 111(6): 063910.

DOI: 10.1063/1.3696975
