The Research, Implementation and Telegram Analysis of IEC61850 Services Mapping to MMS Read

Abstract:

IEC61850 uses the abstract communication service interface (ACSI) and specific communication service mapping (SCSM) definition method. Most of data structure and communication service are mapping to Manufacturing Message Specification (MMS), but MMS has high abstraction, many 61850 ACSI services are mapping to one mms service [6]. At the same time there are many fuzzy definitions even mapping deviation phenomena, different vendors may have inconsistent understanding to the standard, this is harmful to the interoperability. This paper provide analysis and comparison to the 61850 ACSI services mapping to the MMS read, including GetDataValues, GetDataSetValues, GetBRCBValues and so on, and based on these, firstly gives implementation using the mms-ease lite of SISCO Company and detailed explanations of actual telegram. Our research is helpful to eliminate understanding difference and achieve interoperability. System test uses multiple popular software of different company to simulate as server, and the widely used network protocol analyzer software Omicron IEDScout is used to capture packets, the result verifies our implementation satisfy the functionality and interoperability.

• Periodical: Applied Mechanics and Materials (Volume 734)
• Pages: 726-731
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.734.726
• Online since: February 2015
• Authors: Cun Yu*, Gui Ju Li, Huan Hu, Hao Ran Huang, Yan Hong Shen, Xiao You Cui, Jia Liu
• Keywords: ACSI, IEC61850, Interoperability, MMS, SCSM
