A Novel Method for Modeling and Simulation of BLDCM Based on Modular Design

Abstract:

For the imprecise and cumbersome of the brushless DC motor simulation, a novel simulation method based on modular design has been proposed. The Simulation model contains a power supply circuit, a PMSM , and a control unit which uses speed and current double-loop control mode. The outer ring of the double-loop control is speed loop with a PI control, it can stable torque and anti-load disturbance, the inner ring is current loop, with hysteresis current control, plays stable current role. Simulation results showed that the simulation method is precise and runs faster.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 740)

Pages:

321-324

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.740.321

Citation:

Cite this paper

Online since:

March 2015

Authors:

Shuai Yin, Tie Hua Ma*, Yi Lei Zhang

Keywords:

Brushless Dc Motor (BLDCM), MATLAB/SIMULINK, Modeling, Permanent Magnet Synchronous Motor (PMSM), Simulation
