Implementation of DSP Based on Vector Control Model of AC Excitation Control System for a New Hybrid Excitation Synchronous Generator

Abstract:

Permanent magnet generator has the advantages of simple structure, reliable operation and low loss, but it is not easy to adjust voltage, which restricts its wide application. This paper presents a new type of hybrid excitation synchronous generator (HESG) and establishes the mathematical model and simulation of vector control based on its AC excitation system to control the output voltage as the expectation. In application, DSP, as the control system, is traditionally programmed and debugged off-line, which requires heavy workload. Whereas, the design based on model greatly shortens the development cycle. By connecting MATLAB simulation environment to the CCS development environment, the simulation model can be translated into code and downloaded to the targeted DSP through an emulator. This implementation will have specific and indispensable significance for the hardware development and software debugging of motor control system.

• Periodical: Applied Mechanics and Materials (Volume 740)
• Pages: 331-334
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.740.331
• Online since: March 2015
• Authors: Jian Xin Hu*, Ying Jia, Qing Hua Yin
• Keywords: AC Excitation Control System, Design Based on Model, DSP, Hybrid Excitation Synchronous Generator (HESG), MATLAB, Vector Control Model

References

[1] ZhuoRan Zhang, Yangguang Yan, Shanshui Yang, et al.: Principle of Operation and Feature Investigation of a New Topology of Hybrid Excitation Synchronous Machine, Proceedings of the IEEE Transactions on magnetics. Vol. 44, NO. 9, 2008, pp.2174-2180.

DOI: 10.1109/tmag.2008.2000513

[2] T. Kosaka, M. Sridharbabu, M. Yamamoto, et al.: Design studies on hybrid excitation motor for main spindle drive in machine tools, IEEE Transaction on Industrial Electronics. Vol. 57, NO. 11, 2010 , pp.3807-3813.

DOI: 10.1109/tie.2010.2040560

[3] Mingji Liu, Xiaoyan Zhang: Simulation of AC Excitation Field Orientation Control for Hybrid Excitation Synchronous Generator, ICMIC2013, 2013, Vol. 2, pp.879-882.

DOI: 10.1109/mic.2013.6758101

[4] Mingji Liu, Yang Ji, Zhongqin Cai, et al.: Research on the Model and Simulation of Coordinate Structure Hybrid Excitation Synchronous Generator with AC Excitation, The 2 International Conference on Electrical and Control Engineering, Yichang, China, 2011, pp.2616-2619.

DOI: 10.1109/iceceng.2011.6057276

[5] Naigang Hong, et al. ：Model and Simulation of power electronics, motor control system, Machinery Industry Press, (2010).

[6] Jie Liu, Yubo Zhou, et al.: The design based on model-MSP430/F28027/F28335 DSP article, National Defense Industry Press, (2011).
