Vibration Response Analysis on Spindle System of Milling Machine

Abstract:

The dynamic characteristics and dynamics parameters of rolling bearings is very important to dynamics and vibration response of rotate machine such as rotor systems, gear systems and Spindle systems. The frequencies of rotate machine are affected by dynamics parameters of rolling bearings at different places. The purpose in the work presented is to research a new approach and multibody model of Spindle systems with equivalent dynamics parameters of rolling bearings. The flexible Spindle body has been constructed by the fixed interface component mode method. The four different models of rolling bearings for Spindle systems have been developed using equivalent spring and damper elements. The experiments of Spindle body and Spindle system have been carried out. Experimental modal frequencies have been got by impulse vibration test and sweep frequency vibration test. The frequencies and vibration response of Spindle systems have been calculated by adjusting equivalent spring and damper elements to minimizing errors between the calculated and experiment frequencies. The results show the errors of frequencies of linear equal and unequal spring and damper models are large except the first frequency. However, the errors of nonlinear equal and unequal spring and damper models are small. The predicted frequencies of nonlinear unequal spring and damper model are the most accurate and agree well with the experiment results. The presented method can be applied to calculate the nonlinear equivalent stiffness parameters accurately for rolling bearings in multibody systems.
