Scheme Based on Economic Analysis of Energy Consumption about Lithium-Electric Excavator Hydraulic System

Abstract:

The Lithium-electric Excavator Hydraulic System (Li-EEHS) is based on economic analysis of energy consumption, and it has changed the excavator counterweight into Lithium-ion Battery in order to replace the engine. A computational analysis which takes the Qingdao heavy industry excavator HW130 as the example demonstrates the accessibility of the scheme. The total efficiency of the excavator has been improved from 7% to 17.1% by the Li-EEHS without energy regeneration, while the cost has been decreased from 750¥/day into 240¥/day. And the cost recovery will take around 3.3 years (about 500,000¥).The article typically analyzes the system scheme and the working features for 4 major Li-EEHS.

• Periodical: Applied Mechanics and Materials (Volume 741)
• Pages: 558-562
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.741.558
• Online since: March 2015
• Authors: Yong Zhi Ma*, Qing Song Hua, Zhen Yu Huang, Tie Zhu Zhang
• Keywords: Economic Analysis of Energy Consumption, Excavator, Hydraulic System, Lithium-Ion Battery, scheme

References

[1] ZHU Chuanbao, TU Xiaodan, DENG Yuan: Research on the Energy Saving Control System, CONSTRUCTION MACHINERY TECHNOLOGY & MANAGEMENT2011, 24(5): 109.

[2] Paolo Casoli, AlvinAnthony: Gray box modeling of an excavator's variable displacement hydraulic pump for fast simulation of excavation cycles. Control EngineeringPractice. 21(2013): 483–494.

DOI: 10.1016/j.conengprac.2012.11.011

[3] Masayuki KAGOSHIMA, Masayuki KOMIYAMA，Takao NANJO, et a1. Development of New Hybrid Excavator [J]. KOBELCO TECHNOLOGY REVIEW No. 27 NOV 2007.: 39-40.

[4] Tianliang Lin, Qingfeng Wang, Baozan Hu, Wen Gong: Development of hybrid powered hydraulic construction machinery, Automation in Construction 19 (2010)：12–14.

DOI: 10.1016/j.autcon.2009.09.005

[5] LI Fengbing, XIE Kaigui, ZHANGXuesong, ZHAO Bo, CHEN Jian: Optimization of Coordinated Control Parameters for Hybrid Energy StorageSystem Based on Life Quantization. Automation of Electric Power Systems. 2014, 38(1): 3"In Chinese.

[6] RuiXiufeng: The research of pure electric car battery charging system. AnHui University of Science and Technology. 2012: 14"In Chinese.

[7] AI Xinping: Discussion on the Development Trend of the Next Generation of Power Battery and Material. Advanced Materials Industry. 2012(9): 10-11"In Chinese.

[8] LinTianliang: Research on the Potential Energy Regeneration System based on the Hybrid Hydraulic Excavator. Zhejiang University. 2011: 32"In Chinese.
