Research Based on Reverse Engineering Technology of Complex Structure Product

Abstract:

Introduced reverse engineering technology and working principle. Researched reverse design process of the complex curved surface "spider". The data were collected by means of multiple scanning measuring with laser scanner. Used Geomagic Studio software for date point cloud processed of complex curved surface. Used UG software for surface reconstruction designed. Product reduction and improvement of the design were finished rapidly and high quality. Model of spider was printed with rapid prototyping technology. Compared with physical, the model’s reliability and accuracy were verified by reverse engineering design.Keywords: complex surface; reverse engineering technology; UG; Geomagic Studio software

• Periodical: Applied Mechanics and Materials (Volume 741)
• Pages: 806-809
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.741.806
• Online since: March 2015
• Authors: Ai Qin Lin, Yong Xi He
• Keywords: Complex Surface, Geomagic Studio Software, Reverse Engineering Technology, UG
