Measurement Uncertainty Sources Analysis and Verification of Time-Grating with Variable Coupling Coefficient

Abstract:

In order to improve the precision of Time-grating with Variable Coupling Coefficient, the electrical traveling wave equation was derived in detail base on the further study of working principle of Time-grating sensor. Combined with the processing and assembling methods of sensor, the uncertainty sources of sensor standing wave, synthesis traveling wave signal and the produce reasons of higher harmonic were analyzed by using uncertainty theory. The produce reasons of higher harmonic were verified with spectral analysis of the original sensor error data, and then the primary and secondary uncertainty sources affected the sensor measurement uncertainty sources were got, which were time and spatial orthogonal error, amplitude error of two roads signal and stator and rotor air gap uneven. The conclusion made in this paper can be used to conduct the structure optimal design, sensor error correction and uncertainty evaluation.

• Periodical: Applied Mechanics and Materials (Volume 742)
• Pages: 65-70
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.742.65
• Online since: March 2015
• Authors: Hong Tao Yang*, Bin Fan, Jiao Zhou, Ye Tai Fei, Dong Lin Peng
• Keywords: Higher Harmonic, Spectral Analysis, Time-Grating with Variable Coupling Coefficient, Traveling Wave Equation, Uncertainty Sources

References

[1] Yang Wei. Design of time-grating sensor based on variable coupling coefficient transformer[J]. Chinese Journal of Scientific Instrument 2006, 27(11): 1403-1405.

[2] Wu Liang. Research on Time-grating based on Variable Coupling Coefficient[M]. Chongqing University of technology.

[3] PENG Dong-lin. High-precision Time-grating Displacement Sensor Based on Harmonic Wave Correcting Method[J]. Chinese Journal of Scientific Instrument2006, 27(1): 31-33.

[4] PENG Dong-lin. New Method of Postprocessing in Time-grating with Variable Coupling Coefficient[J]. Instrument Technique and sensor 2012. 11: 31-33.

[5] FEI Y T. Error Theory and Data Processing[M]. Beijing: China Machine Press，(2005).

[6] WU Liang. Design of Time Grating Sensor Based on Standing Wave Modulation[J]. Instrument Technique and sensor2011. 4: 4-6.

[7] PENG Dong-lin. Study on the Theory of Time-grating Coordinate Transformation and the Time Grating Displacement Sensor[J]. Chinese Journal of Scientific Instrument.
