Application of Finite Element Analysis to the Interface Decohesion of CFRP/SMA Composite

Abstract:

In this work, finite element calculations were carried out to simulate wire pullout process of the shape memory alloy (SMA) wire/carbon fiber reinforced polymer (CFRP) hybrid composite. Three-dimensional cohesive zone model was used for the bonding interface between the SMA and the CFRP. Phase transformation behavior of the SMA wire was accounted for by using a multi-variant constitutive model. The numerical parameters were fitted using an experimental measurement reported by Jang and Kishi. Young’s modulus of the wire affected the force vs. elongation curve most effectively. It is shown that the actual shear stress profile is not constant but it varies significantly along the axial direction of the wire. Additional toughness due to the SMA wire was higher than the case of a purely elastic wire, and the toughness increment was approximately 21 kJ/m². This value is comparable to the typical toughness value of CFRP.

• Periodical: Applied Mechanics and Materials (Volumes 752-753)
• Pages: 125-129
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.752-753.125
• Online since: April 2015
• Authors: Noh Yu Kim, Sung Young*
• Keywords: Cohesive Zone Model, Composite, Fiber Pullout, Finite Element Analysis (FEA)

References

[1] B.J. Blaiszik, N.R. Sottos and S.R. White, Nanocapsules for self-healing materials, Comp. Sci. and Technol. 68 (2008) 978-986.

DOI: 10.1016/j.compscitech.2007.07.021

[2] S. Neuser, V. Michaud and S.R. White, Improving solvent-based self-healing materials through shape memory alloys, Polymer, 53 (2012) 370-378.

DOI: 10.1016/j.polymer.2011.12.020

[3] Y. Xu, K. Otsuka, H. Yoshida, H. Nagai, R. Oishi, H. Hirikawa and T. Kishi, A new method for fabricating SMA/CFRP smart hybrid composites, Intermetallics, 10 (2002) 361-369.

DOI: 10.1016/s0966-9795(02)00011-0

[4] S.Y. Yang, B.C. Goo and H.J. Kim, Mechanical Behavior of Shape Memory Alloy Composites, Key Eng. Mater. 297-300 (2005) 1551-1558.

DOI: 10.4028/www.scientific.net/kem.297-300.1551

[5] Cornerstone Research Group Inc. http: /www. crgrp. com/technology/overviews/composites. html.

[6] B.K. Jang and T. Kishi, Adhesive strength between TiNi fibers embedded in CFRP composites, Materials Letters, 59 (2005) 1338-1341.

DOI: 10.1016/j.matlet.2005.01.006

[7] M.S. Huang and L.C. Brinson, A Multivariant model for single crystal shape memory alloy behavior, J. Mech. Phy. Sol. 46 (1998) 1379-1409.

DOI: 10.1016/s0022-5096(97)00080-x

[8] A.V. Idesman, V.I. Levitas, D.L. Preston and J.Y. Cho, Finite element simulations of martensitic phase transitions and microstructures based on a strain softening model, J. Mech. Phy. Sol. 53 (2005) 495-523.

DOI: 10.1016/j.jmps.2004.10.001

[9] S.Y. Yang, J. Escobar and R.J. Clifton, Computational Modeling of Stress-Wave-Induced Martensitic Phase Transformations in NiTi, Math. Mech. of Sol. 14 (2009) 220-257.

DOI: 10.1177/1081286508092613

[10] A. Needleman, A Continuum Model for Void Nucleation by Inclusion Debonding, J. Appl. Mech. 54 (1987) 525-531.

DOI: 10.1115/1.3173064

[11] J.H. Rose, J. Ferrante and J.R. Smith, Universal Binding Energy Curves for Metals and Bimetallic Interfaces, Phy. Rev. Let. 47 (1981) 675-678.

DOI: 10.1103/physrevlett.47.675

[12] A. De-Andres, J.L. Perez and M. Ortiz, Elastoplastic finite element analysis of three-dimensional fatigue crack growth in aluminum shafts subjected to axial loading, Int. J. Sol. Struc. 36 (1999) 2231-2258.

DOI: 10.1016/s0020-7683(98)00059-6

[13] S.Y. Yang, Cohesive Zone Parameters for the Interface between NiTi Shape Memory Alloy and CFRP, Key Eng. Mater. 321-323 (2006) 196-199.

DOI: 10.4028/www.scientific.net/kem.321-323.196

[14] M.F. Ashby and D.R.H. Jones: Engineering materials 2. (Pergamon Press, UK 1999).
