Dynamics Analysis of Energy Absorbing Device Based on Damped Dynamics Vibration Absorber

Abstract:

Nowadays, absorbing energy from vibration is one of the most promising technologies. In general, the vibrations may be very large, such as the vibrations of tall buildings, large flexible bridges, and ocean platform and so on in some environmental loading. With the global concern on energy and environmental issues, energy absorbing from large-scale vibrations for structural health monitoring purposes is more attractive and becomes a research frontier. A type of damped dynamics vibration energy absorber, where two masses are connected in series with the energy transducer and spring, is built and analyzed in this paper. The relationships among electrical damping ratio, excitation frequency ratio and dimensionless power are analyzed in frequency domain. The optimal parameters for maximizing the power output are discussed in analytical form while taking the parasitic mechanical damping of the system into account. In addition, the numerical simulations in time domain are calculated. The results indicate that when the system is excited by the larger peak of local optimal excitation frequency, more power can be obtained. It is helpful for design of energy absorber device.

• Periodical: Applied Mechanics and Materials (Volumes 764-765)
• Pages: 254-258
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.764-765.254
• Online since: May 2015
• Authors: Zhong Qiang Zheng, Peng Huang, Tao Yao, Zong Yu Chang*
• Keywords: Dynamic, Dynamic Vibration Absorber, Energy Absorbing, Power

References

[1] Williams, C. & Yates, R.: 1996. Analysis of a Micro-Electric Generator for Microsystems, Sensors Actuators A Phys., 52: 8-11.

DOI: 10.1016/0924-4247(96)80118-x

[2] Sodano, H. A. Inman, D. J. & Park, G.: 2004. A Review of Power Harvesting From Vibration Using Piezoelectric Materials, Shock Vib. Dig., 36(3): 197-205.

DOI: 10.1177/0583102404043275

[3] Collins, L.: 2006. Harvesting for the world: energy harvesting techniques, IEEE Power Engineer, 20: 34-37.

[4] Paradiso, J. & Starner, T.: 2005 Energy scavenging for mobile and wireless electronics, IEEE Pervasive Computing 4 (1): 18-26.

DOI: 10.1109/mprv.2005.9

[5] Beeby, S. P. Tudor, M. J. & White, N. M.: 2006. Energy Harvesting Vibration Sources for Microsystems Applications, Meas. Sci. Technol., 17(12): 175-195.

DOI: 10.1088/0957-0233/17/12/r01

[6] Anton, S. R. & Sodano, H. A.: 2007. A Review of Power Harvesting Using Piezoelectric Materials (2003–2006), Smart Mater. Struct., 16(3): R1-R21.

DOI: 10.1088/0964-1726/16/3/r01

[7] Hartog, J. P. D.: 1985. Mechanical Vibrations, Dover, New York.

[8] Lee, S. Youn, B. & Jung, B.: 2009. Robust segment-type energy harvester and its application to wireless sensor, Smart Materials and Structures, 18: 095021.

DOI: 10.1088/0964-1726/18/9/095021

[9] Tang, X.D. & Lei, Z.: 2011. Enhanced vibration energy harvesting using dual-mass systems. Journal of Sound and Vibration, 330: 5199-5209.

DOI: 10.1016/j.jsv.2011.05.019
