Estimation for Temperature Distribution of PET Preform Surface under Multiple Lamps

Abstract:

PET prefom surface temperature distribution is a key factor for getting the better quality of construction a bottle by stretch blow molding (SBM) machine. To get a better temperature distribution, different types of prefom under different number of infrared lamps heating conditions are worth to investigate the position of each lamp as well as its power intensity. In this study, we first try to use adaptive finite volume method to estimate the proper intensity of each lamp so that the combination strength will make good result about the temperature distribution. Then we make experiments to confirm each case. We have five, six, and seven heating lamps cases to present. With these estimations, we find that five lamps case can do equal quality about the temperature distribution comparing with six and seven lamps cases. This means that we offer a method for finding one saving energy way to produce PET bottle by SBM machine. A more detail analysis about inside PET bottle temperature distribution will be deliberated in future.

• Periodical: Applied Mechanics and Materials (Volumes 764-765)
• Pages: 269-273
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.764-765.269
• Online since: May 2015
• Authors: Yi Chern Hsieh*, Minh Hai Doan, Chien Min Hung
• Keywords: Multiple Lamps, PET Heating, Temperature Distribution

References

[1] M. Bordival, Schmidt F.M., Le Maoult Y., Velay V.: Optimization of Preform Temperature Distribution for the Stretch-Blow Molding of PET Bottles: Infrared Heating and Blowing Modeling, Polym. Eng. Sci. 49: 783-793, (2009).

DOI: 10.1002/pen.21296

[2] Monteix S., Schmidt F., Le Maoult Y., Yedder R.B., Diraddo R.W., Laroche D.: Experimental study and numerical simulation of preform sheet exposed to infrared radiative heating. J. Mater. Proc. Tech., 119: 90-97, (2001).

DOI: 10.1016/s0924-0136(01)00882-2

[3] Frank P. Incropera, David P. Dewitt: Fundamentals of Heat and Mass Transfer, Fourth edition, Chapter 13, pp.718-755.

[4] Jinn-Liang Liu, Ing-Jer Lin, Miin-Zhih, Ren-Chuen Chen, Mao-Chung Hsieh: Object- oriented programming of adaptive finite element and finite volume methods, Applied Numerical mathematics, Volume 21, Issue 4, Pages 439-467, (1996).

DOI: 10.1016/s0168-9274(96)00044-x

[5] Yi- Chern Hsieh, Doan Minh Hai, Pham Thi Thanh Hoi: The Study of Infrared Heating on PET Bottles by Experiment and Adaptive Finite Volume Method: Advanced Materials Research, Vols. 591-593 (2012) pp.750-753.

DOI: 10.4028/www.scientific.net/amr.591-593.750

[6] Ph. Lebaudy, J. M. Saiter, J. Grenet and C. Vautier: Temperature distribution in poly(ethylene terephthalate) plate undergoing heat treatment. Diffusion influence and application : Polymer, Vol. 36 No. 6, pp.1217-1221, (1995).

DOI: 10.1016/0032-3861(95)93923-a

[7] J. P. MCEVOY, * C. G. ARMSTRONG, and R. J. CRAWFORD : Simulation of the Stretch Blow Molding Process of PET Bottles: Advances in Polymer Technology, Vol. 17, No. 4, 339– 352, (1998).

DOI: 10.1002/(sici)1098-2329(199824)17:4<339::aid-adv5>3.0.co;2-s
