Finite Element Analysis on Natural Properties of a Micro Drill with Ultrasonic Vibration

Abstract:

Finite element analysis on natural properties of a micro drill with ultrasonic vibration is considered to study. Because getting smaller aperture in the printed circuit board (PCB), it tends to be more severe due to vibration. The vibration has adverse effects to machining accuracy and surface roughness which will increase tool abrasion and further accelerate the destruction from material fatigue. There are many ways to produce perforations, such as laser micro-machining and micro-drilling. The industry still adopts micro drill piercing process due to the cost and technical considerations. In order to enhance the cutlery life and the quality of the drilling process, the cutting characteristic of bur is important. Hence, the vibration during drilling must be suppressed. This study is to investigate the natural properties of a micro drill under ultrasonic vibration (50 kHz) excited with a piezoelectric-driven actuator and numerically by using finite element analysis.

• Periodical: Applied Mechanics and Materials (Volumes 764-765)
• Pages: 285-288
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.764-765.285
• Online since: May 2015
• Authors: Bo Wun Huang*, Wu Tsan Chen, Jung Ge Tseng
• Keywords: Finite Element Method (FEM), Micro-Drilling, Natural Properties, Ultrasonic

References

[1] X. Lei, B. Shen, L. Cheng, F. Sun, M. Chen: Int. J. Refract. Met. H. Vol. 43 (2014), p.30.

[2] M. Aziz, O.O. Osamu, H. Onikura: Precis. Eng. Vol. 36 (2012), p.168.

[3] S.C. Shih, in: Study of the tribology characteristics of tungsten carbide micron-drill on PCB, Master Thesis, Department of Mechanical Engineering, National Cheng Kung University, Taiwan (2000).

[4] J.K. Chen, in: The research of tungsten-doped hydrogen-free diamond-like carbon micron drills on PCB micro hole drilling, Master Thesis, Department of Mechanical Engineering, National Cheng Kung University, Taiwan (2001).

[5] Y.P. Gong, K.F. Ehmann, C. Lin: J. Mater. Process. Technol., Vol. 141 (2003), p.16.

[6] B.K. Hinds, G.M. Treanor: Int. J. Mach. Tool Manu., Vol. 40 (2000), p.1443.

[7] W.H. Shih, in: Study and Analysis on Precision Machining of Microdrills, Master Thesis, Department of Mechanical Engineering, National Taiwan University, Taipei, Taiwan (2002).

[8] C.S. Liu, in: Finite Element Analysis and Experimental Investigation of Run-Out in Micro-Drills, Master Thesis, Department of Mechanical Engineering, National Chung Cheng University, Taiwan (2002).

[9] H.W. Chen, in: The High-Speed Drilling Performance of PCB Micro-Drill with Different Geometry Design, Master Thesis, Department of Mechanical Engineering, National Cheng Kung University, Taiwan (2002).

[10] W.S. Liang, in: Research on determining the optimal micro-drilling parameters for the PCB and measuring the flank wear, Master Thesis, Department of Mechanical Engineering, National Taiwan University of Science and Technology, Taiwan (2004).

[11] Y.H. Chiu, in: Using the Design of Experiment, (DOE) method to find out the optimum parameters of micro drill on PCB, Master Thesis, Department of Mechanical Engineering, National Central University, Taiwan (2007).

[12] B.W. Huang, S.M. Wu, in: Analytical solution of Free vibration of a high-speed drill, Thematic Research Report, National Science Council (NSC89-2212-E-230 -006), Taiwan (2000).
