FEM Simulation and Experimental Verification on Rotating Compression Forming of Double-Layer Clad Ring Considering Shear Friction

Abstract:

This study uses FEM simulation based on Deform 3D commercial software to explore the plastic behaviors in the rotating compression of double-layer bounded clad ring under constant shear friction. The effective stress, the effective strain, the velocity field, the compression force under various forming conditions can be determined from FEM simulation. The realistic experiment has been performed to verify the acceptance of FEM simulation. From the comparisons, the compression force and free surfaces of outer and inner diameters shows a good agreement with the experiments, it proves the FEM simulation can be accepted as industry references.

• Periodical: Applied Mechanics and Materials (Volumes 764-765)
• Pages: 280-284
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.764-765.280
• Online since: May 2015
• Authors: Gow Yi Tzou*, Yeong Maw Hwang, Hsiang Yu Teng
• Keywords: Bounded Clad Ring, Constant Shear Friction, Double-Layer, Rotating Compression

References

[1] S. Alexandrov, G.Y. Tzou, S.Y. Hsia:, 2004. A New Upper Bound Solution For a Hollow Cylinder Subject to Compression and Twist, Journal of Mechanical Engineering Science, Vol. 218(2004), pp.369-375.

DOI: 10.1177/095440620421800402

[2] C.C. Chang, G.Y. Tzou, W.T. Chien, D.L. Tsai,: Investigation on the Rotating Compression Forming of Cylinder With Constant Shear Friction, The 31th National Conference on Theoretical and Applied Mechanics, (2007), pp. J20-01-J20-05.

[3] C.J. Chen, G.Y. Tzou, M.N. Huang:, Study on the Twist Compression Forming of Cylinder Based on the Upper Bound and Slab Method, Journal of Materials Processing Technology, Vol. 174(2006), pp.266-271.

DOI: 10.1016/j.jmatprotec.2005.06.091

[4] J.R. Douglas and T. Altan,: Flow Stress Determination For Metals at Forging Rates and Temperatures, Journal of Engineering for Industry, (1975), pp.66-76.

DOI: 10.1115/1.3438593

[5] M.N. Huang and G.Y. Tzou,: Study on Compression of a Rotating Disk Considering Hybrid Friction, Journal of Materials Processing Technology, Vol. 125-126(2002), pp.421-426.

DOI: 10.1016/s0924-0136(02)00293-5

[6] M.N. Huang and G.Y. Tzou:, New Corresponding Relationships Between Frictional Coefficient and Frictional Factor in Compression Forming of a Rotating Circular Disk, Key Engineering Materials, Vol. 274-276(2004), pp.409-414.

DOI: 10.4028/www.scientific.net/kem.274-276.409

[7] H.H. Hsu, and G.Y. Tzou:, Two analytical models of double-layer clad sheet compression forming based on the upper bound and the slab methods, Journal of Materials Processing Technology, Vol. 140(2003), pp.604-609.

DOI: 10.1016/s0924-0136(03)00800-8

[8] Y.H. Kim, J.H. Park, Y.E. Jin:, An Analysis of Plastic Deformation Process For Twist-Assisted Upset forging of Cylindrical Billets, Proceedings of the Institution of Mechanical Engineering, Part B, Journal of Engineering Manufacture, Vol. 215(2001).

DOI: 10.1243/0954405011518674

[9] Y.H. Kim, J.H. Park, Y.E. Jin,: An Upper Bound Analysis For Torsional Upset Forging of Cylindrical Billets, Proc. of 6th International Conference on Technology of Plasticity, Vol. 2(1999), pp.859-864.

[10] Y.H. Kim, Y.E. Jin, J.H. Park, Y. Lee,: An Analysis of the Torsional Forming Process Using the Dual Stream Function, Proc. of the 8th International Conference on Metal Forming, (2000), pp.741-745.

[11] H. Sofuoglu, and J. Rasty,: On the Measurement of Friction Coefficient Utilizing the Ring Compression Test, Tribology International, Vol. 32(1996), pp.327-335.

DOI: 10.1016/s0301-679x(99)00055-9

[12] G.Y. Tzou, M.N. Huang, C.J. Chen,: An Analytical Approach to Rotating Compression Forming of Circular Disk Considering Constant Shear Friction, International Symposium on Plasticity and its Current Applications, (2002), pp.445-447.

[13] G.Y. Tzou, M.N. Huang, Y.M. Huang, H.L. Hu,: Analysis and Experimental Verification on the Rotating Compression Forming of Cylinder, Journal of the Chinese Society of Mechanical Engineers, Vol. 27(2004), pp.687-692.

[14] G.Y. Tzou, W.T. Chien, M.N. Huang, D.L. Tsai,: Slab Analysis of Rotating Compression Forming of Cylinder With Coulomb Friction, The 5th Conference on Precision Machinery and Manufacturing Technology, Vol. 125-126(2007), pp.421-426.

[15] G.Y. Tzou, W.T. Chien, M.N. Huang, D.L. Tsai:, Analytical Model of Rotating Compression Forming of Cylinder With Hybrid Friction, The 24th National Conference on Mechanical Engineering The Chinese Society of Mechanical Engineers, (2007).

[176] K.M. Xua, Z. Wang, Y. Lu:, FEM Analysis of Cylinder Twist Compression Deformation Regularity, Journal of Materials Processing Technology, Vol. 69(1997), pp.148-151.

DOI: 10.1016/s0924-0136(97)00008-3
