Condition Monitoring of Variable Speed Worm Gearbox Lubricated with Different Viscosity Oils

Abstract:

Over the years, condition monitoring of gear transmission systems have captured significant worldwide attention from both industries and academia. This is in light of the fact that an effective condition monitoring techniques will unquestionably extend the life span of the rotating equipment. In this research, both the vibration and temperature monitoring techniques were utilized to characterize the vibration behavior of worm gear as function of gear lubricant’s viscosity. Three different types of lubricant’s viscosity; VG100, VG460 and VG680 were used in the study to serve the sliding friction of worm gears. The predetermined speeds of electric motor at 900, 1150 and 1400 rpm were introduced to the gearbox prior to the measurement of vibration signal and temperature profile. The results revealed that a lubricant with higher viscosity contributes to less vibration amplitude. At 1150 rpm, it was recorded that the vibration amplitudes are higher compare to the other motor speeds, for all lubricant's types. In this case, VG100 showed the highest vibration amplitude followed by VG460 and VG680. This result was corroborated well with the obtained temperature profiles which are 35.0°C, 35.7°C and 39.3°C for the respective VG100, VG460 and VG680. Thus, concludes the correlation between the lubrication’s viscosity, vibration level, temperature profile and worm gear speed.

• Periodical: Applied Mechanics and Materials (Volumes 773-774)
• Pages: 178-182
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.773-774.178
• Online since: July 2015
• Authors: Maznan Bin Ismon, Izzuddin Bin Zaman*, Mohd Imran Ghazali
• Keywords: Condition Monitoring, Thermograph, Vibration, Worm Gear

References

[1] M. Amarnath, C. Sujatha, S. Swarnamani, Experimental studies on the effect of reduction in gear tooth stiffness and lubricant film thickness in a spur geared system, Tribology International 42 (2009) 340-352.

DOI: 10.1016/j.triboint.2008.07.008

[2] G. Bonori, F. Pellicano, Non-smooth dynamics of spur gears with manufacturing errors, Journal of Sound and Vibration 306 (2007) 271-283.

DOI: 10.1016/j.jsv.2007.05.013

[3] M.D. Brouwer, L.A. Gupta, F. Sadeghi, D. Peroulis, D. Adams, High temperature dynamic viscosity sensor for engine oil applications, Sensors and Actuators, A: Physical 173 (2012) 102-107.

DOI: 10.1016/j.sna.2011.10.024

[4] B.C. Sharma, O.P. Gandhi, Performance evaluation and analysis of lubricating oil using parameter profile approach, Industrial Lubrication and Tribology 60 (2008) 131-137.

DOI: 10.1108/00368790810871057

[5] I. Zaman, A. Khalid, B. Manshoor, S. Araby, M.I. Ghazali, The effects of bolted joints on dynamic response of structures, IOP Conference Series: Materials Science and Engineering 50 (2013) 012018.

DOI: 10.1088/1757-899x/50/1/012018

[6] Z. Peng, N.J. Kessissoglou, M. Cox, A study of the effect of contaminant particles in lubricants using wear debris and vibration condition monitoring techniques, Wear 258 (2005) 1651-1662.

DOI: 10.1016/j.wear.2004.11.020

[7] M. Elforjani, D. Mba, A. Muhammad, A. Sire, Condition monitoring of worm gears, Applied Acoustics 73 (2012) 859-863.

DOI: 10.1016/j.apacoust.2012.03.008

[8] I. Zaman, B. Manshoor, A. Khalid, S. Araby, M.I. Ghazali, Vibration characteristics of composite plate embedded with shape memory alloy at elevated temperature, Applied Mechanics and Materials 393 (2013) 655-660.

DOI: 10.4028/www.scientific.net/amm.393.655

[9] I. Zaman, M.M. Salleh, M. Ismon, B. Manshoor, A. Khalid, M.S.M. Sani, S. Araby, Vibration attenuation of plate using multiple vibration absorbers, MATEC Web of Conferences 13 (2014) 03003.

DOI: 10.1051/matecconf/20141303003
