Design and Analysis of a Digital Controller for Boost Converter with Renewable Energy Sources for Domestic DC Load

Abstract:

Renewable energy sources like solar PV produces DC voltage which is converted to AC before connecting to domestic grid network. The conversion process from DC to AC and back to DC at load end introduce additional losses in the system. With increasing availability of modern DC loads and growing use of renewable energy, the use of DC network for domestic load supply is on increase in order to reduce energy conversion losses. Presented in this paper is a fast transient digital controller for DC-DC boost converter with energy source from solar PV for domestic DC loads like lightings. The boost converter was model as both steady and dynamic state. Digital controllers were designed using both digital redesign approach and direct digital redesign approach. The system demonstrated fast transient response that is essential for tightly regulated output voltage from constantly varying renewable energy generations.

• Periodical: Applied Mechanics and Materials (Volume 785)
• Pages: 141-145
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.785.141
• Online since: August 2015
• Authors: Oladimeji Ibrahim*, N.Z. Yahaya, N. Saad, K.Y. Ahmed
• Keywords: Closed Loop Response, DC Load, DC/DC Boost Converter, Digital Compensator

References

[1] J. J. Justo, F. Mwasilu, J. Lee, and J. -W. Jung, AC-microgrids versus DC-microgrids with distributed energy resources: A review, Renewable and Sustainable Energy Reviews, vol. 24, pp.387-405, (2013).

DOI: 10.1016/j.rser.2013.03.067

[2] M. J. Sarker, B. Asare-Bediako, J. Slootweg, W. Kling, and B. Alipuria, DC micro-grid with distributed generation for rural electrification, in Universities Power Engineering Conference (UPEC), 2012 47th International, 2012, pp.1-6.

DOI: 10.1109/upec.2012.6398580

[3] S. Chakraborty, M. G. Simões, and W. E. Kramer, Power Electronics for Renewable and Distributed Energy Systems: Springer, (2013).

[4] J. M. Carrasco, L. G. Franquelo, J. T. Bialasiewicz, E. Galván, R. P. Guisado, M. A. Prats, et al., Power-electronic systems for the grid integration of renewable energy sources: A survey, Industrial Electronics, IEEE Transactions on, vol. 53, pp.1002-1016, (2006).

DOI: 10.1109/tie.2006.878356

[5] C. Buccella, C. Cecati, and H. Latafat, Digital control of power converters—A survey, Industrial Informatics, IEEE Transactions on, vol. 8, pp.437-447, (2012).

DOI: 10.1109/tii.2012.2192280

[6] Y. -F. Liu and P. Sen, Digital control of switching power converters, in Control Applications, 2005. CCA 2005. Proceedings of 2005 IEEE Conference on, 2005, pp.635-640.

DOI: 10.1109/cca.2005.1507198

[7] W. Shireen, A. Nagarajan, and S. Patel, A reliable low cost power electronics interface for photovoltaic energy systems using a single DSP controller, in Power Systems Conference and Exposition (PSCE), 2011 IEEE/PES, 2011, pp.1-6.

DOI: 10.1109/psce.2011.5772560

[8] S. Ang and A. Oliva, Power-switching converters: CRC press, (2005).

[9] V. Jha and P. Rai, State Space Averaged Modeling of Basic Converter Topologies, VSRD International Journal of Electrical, Electronics & Communication Engineering, vol. 2, pp.566-575, (2012).

[10] A. Prodic, D. Maksimovic, and R. W. Erickson, Design and implementation of a digital PWM controller for a high-frequency switching DC-DC power converter, " in Industrial Electronics Society, 2001. IECON, 01. The 27th Annual Conference of the IEEE, 2001, pp.893-898.

DOI: 10.1109/iecon.2001.975878
