Modeling and Simulation of Power Electronic Distribution Transformer Based on a Three Level Converter

Abstract:

In this paper, a new type of power electronic distribution transformer (PET) has been introduced based on the power electronics converter on the primary and secondary sides of the transformer. This PET has three stages and the input stage has a three-level, three-phase rectifier. The middle stage has two three-level single-phase converters and a high-frequency transformer; and, the output stage is a three-phase, two-level inverter. This power electronic distribution transformer provides many advantages, such as power factor improvement, reactive power compensation, eliminating harmonics, and controlling and protecting itself (PET) with minimum size, compared to the traditional transformer. The MATLAB/Simulink was used to analyze and validate the power electronic distribution transformer.

• Periodical: Applied Mechanics and Materials (Volume 785)
• Pages: 151-155
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.785.151
• Online since: August 2015
• Authors: K.Y. Ahmed*, N.Z. Yahaya, V.S. Asirvadam, Oladimeji Ibrahim
• Keywords: High Frequency Transformer, Power Electronic Converter, Power Electronic Transformer, Power Quality

References

[1] S. Ratanapanachote, Applications of an electronic transformer in a power distribution system, Ph. D Dissertation, Electrical Engineering, Texas A&M University, (2004).

[2] K. Y. Ahmed, N. Z. Yahaya, and V. S. Asirvadam, Optimal Analysis and Design of Power Electronic Distribution Transformer, Research Journal of Applied Sciences, Engineering and Technology, vol. 7(9), pp.1734-1743, (2014).

DOI: 10.19026/rjaset.7.457

[3] J. L. Brooks, Solid state transformer concept development, NASA STI/Recon Technical Report N, vol. 81, p.10302, (1980).

[4] EPRI Report, Proof of the principle of the solid-state transformer, " the AC/AC switch mode regulator, EPRI TR-105067, Research Project 8001-13, Final Report, (1995).

[5] K. A. Harada, F. Yamasaki, K. Jinno, M. Kawata, and T. Y Nakashima, Intelligent transformer, Power Electronics, (1996).

[6] M. Kang, P. N. Enjeti, and I. J. Pitel, Analysis and design of electronic transformers for electric power distribution system, Power Electronics, IEEE Transactions on, vol. 14, pp.1133-1141, (1999).

DOI: 10.1109/63.803407

[7] E. R. Ronan, S. D. Sudhoff, S. F. Glover, and D. L. Galloway, A power electronic-based distribution transformer, Power Delivery, IEEE Transactions on, vol. 17, pp.537-543, (2002).

DOI: 10.1109/61.997934

[8] D. Wang, C. Mao, J. Lu, S. Fan, and F. Peng, Theory and application of distribution electronic power transformer, Electric power systems research, vol. 77, pp.219-226, (2007).

DOI: 10.1016/j.epsr.2006.02.012

[9] C. Ling, B. Ge, D. Bi, and Q. Ma, An effective power electronic transformer applied to distribution system, in Electrical Machines and Systems (ICEMS), 2011 International Conference on, 2011, pp.1-6.

DOI: 10.1109/icems.2011.6073552

[10] H. Liu, C. Mao, J. Lu, and D. Wang, Optimal regulator-based control of electronic power transformer for distribution systems, Electric Power Systems Research, vol. 79, pp.863-870, (2009).

DOI: 10.1016/j.epsr.2008.11.003
