Modelling and Simulation an AC-DC Rectifier Circuit Based on Piezoelectric Vibration Sensor for Energy Harvesting System

Abstract:

This paper presents the modeling of a full-wave rectifier circuit based on piezoelectric vibration transducer for energy-harvester system. Piezoelectric vibration crystals are a viable means of harvesting energy for low-power embedded systems e.g. wireless sensor network. Distinct power handling circuits are assessed with the presence of piezoelectric vibration based energy harvesting transducer. Inside the interface circuit, the voltage should be started up when the AC input voltage is very low to supply a regulated DC voltage up to 2V. An active technique is chosen to design an ultra-low power circuit from a piezoelectric vibration transducer. MOSFET bride ac–dc rectifier, energy storage device e.g. capacitor and boost converter with regulator are the common components of the energy harvesting circuits. An integrated promoter ac-dc rectifier circuit and boost converter that accept a maximum input voltage of 0.3V and provide a regulated output voltage of 2V serve as the supply. The MOSFET and thyristor are considered to develop the proposed circuit replacing conventional ac-dc rectifier due to low input voltage at which diode does not work.

• Periodical: Applied Mechanics and Materials (Volume 785)
• Pages: 131-135
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.785.131
• Online since: August 2015
• Authors: Mahidur R. Sarker*, Azah Mohamed, Ramizi Mohamed
• Keywords: AC-DC Matrix Rectifier, Energy Harvesting, Low Voltage, Micro-Device, Piezoelectric

References

[1] M.J. Guan and W.H. Liao. Characteristics of Energy Storage Devices in Piezoelectric Energy Harvesting Systems. Journal of Intelligent Material System and Structure. Vol. 19 (2007), pp.671-680.

DOI: 10.1177/1045389x07078969

[2] S.P. Beeby, M.J. Tudor and N.M. White. Energy harvesting vibration sources for micro systems applications. Measurement Science and Technology. Vol. 17 (2006), pp.175-195.

[3] S. Priya. Advances in energy harvesting using low profile piezoelectric transducers. Journal of Electro ceramics. Vol. 19 (2007), p.167–184.

DOI: 10.1007/s10832-007-9043-4

[4] S. J. Roundy. On the effectiveness of vibration-based energy harvesting. Journal of Intelligent Material Systems and Structures. Vol. 16 (2005), pp.809-823.

DOI: 10.1177/1045389x05054042

[5] S.E. Park and T.R. Shrout. Ultrahigh strain and piezoelectric behaviour in relaxer based ferroelectric single crystals. Journal of Applied Physics, Vol. 82 (1997), pp.1804-1811.

DOI: 10.1063/1.365983

[6] R. Murugavel and M. Grazier. ULP meets energy harvesting. Texas Instrument. (2010) pp.1-7.

[7] K.T. Yen and K.P. Sanjib. Optimized wind energy harvesting system using resistance emulator and active rectifier for wireless sensor nodes. IEEE Transactions on Power Electronics. Vol. 26 (2011), pp.38-50.

DOI: 10.1109/tpel.2010.2056700

[8] N. J. Guilar, R. Amirtharajah and P. J. Hurst. A full-wave Rectifier with integrated peak selection for multiple electrode piezoelectric energy harvester. Vol. 44 (2009), pp.240-246.

DOI: 10.1109/jssc.2008.2007446

[9] G.K. Ottman, H.F. Hofmann, A.C. Bhatt and G.A. Lesieutre. Adaptive piezoelectric energy harvesting circuit for wireless remote power supply. IEEE Transactions on Power Electronics. Vol. 17(2002), pp.669-676.

DOI: 10.1109/tpel.2002.802194
