Microstructure and Tensile Properties of Friction Stir and Gas Tungsten Arc Welded AZ91D Magnesium Alloy Joints

Abstract:

Influence of a fusion welding process namely gas tungsten (GTAW) and a solid state friction stir welding (FSW) on the microstructural changes and tensile strength variation of cast magnesium alloy joints were investigated and the results are compared. Of the two joints fabricated, FSW joint showed superior tensile properties compared to GTAW joint due to the difference in microstructural gradient across the weld cross section. Wider partially melted zone and heat affected zone was observed in GTAW joint due to the high heat input nature process compared to narrow heat affected zone in FSW joint. Microhardness measurement indicates that, the weld metal is overmatched compared to the base metal irrespective of welding process used.

• Periodical: Applied Mechanics and Materials (Volume 787)
• Pages: 470-474
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.787.470
• Online since: August 2015
• Authors: A. Shanmugasundaram, A.K. Lakshminarayanan, V.E. Annamalai
• Keywords: Friction Stir Welding, Gas Tungsten Arc Welding, Magnesium Alloy, Tensile Properties

References

[1] Jun Shen, Guoqiang You, Siyuan Long, Fusheng Pan, Abnormal macropore formation during double-sided gas tungsten arc welding of magnesium AZ91D alloy, Materials Characterization. 59 (2008) 1059 – 1065.

DOI: 10.1016/j.matchar.2007.08.021

[2] W. Zhou, T. Z. Long and C. K. Mark, Hot cracking in tungsten inert gas welding of magnesium alloy AZ91D, Materials Science and Technology. 23 (2007) 1294-1299.

DOI: 10.1179/174328407x213026

[3] A. Munitz, C. Cotler, A. Stern, G. Kohn, Mechanical properties and microstructure of gas tungsten arc welded magnesium AZ91D plates, Materials Science and Engineering A. 302 (2001) 68–73.

DOI: 10.1016/s0921-5093(00)01356-3

[4] Won-Bae Lee, Jong-Woong Kim, Yun-Mo Yeon, Seung-Boo Jung, The Joint Characteristics of Friction Stir Welded AZ91D Magnesium Alloy, Materials Transactions. 44 (2003) 917-923.

DOI: 10.2320/matertrans.44.917

[5] SHC Park, Y.S. Sato, H. Kokawa, Microstructural evolution and its effect on hall petch relationship in friction stir welding of thixomolded Mg alloy AZ91D, Journal of materials science. 38 (2003) 4379-4883.

[6] A. Kouadri-Henni and L. Barrallie, Mechanical Properties, Microstructure and Crystallographic Texture of Magnesium AZ91-D Alloy Welded by Friction Stir Welding (FSW), Metallurgical and Materials Transactions A. 45 (2014) 4983-4996.

DOI: 10.1007/s11661-014-2381-3
