Bi-Directional Z-Source Inverter for Superconducting Magnetic Energy Storage Systems

Abstract:

Superconducting magnetic energy storage (SMES) is basically a DC current energy storage technology which stores energy in the form of magnetic field. The DC current flowing through a superconducting coil in a large magnet creates the magnetic field. Because of its fast response during charging and discharging, ability of injecting/absorbing real or reactive power, high storage efficiency, reliability and availability, the SMES technologies are used in power system transmission control and stabilization, and power quality improvement. Generally, an SMES consists of the superconducting coil, the cryogenic system, and the power conversion system. The power conversion system normally uses a power electronic converter as an interface between the coil and AC output. This converter is needed to act as the boost converter during DC side to AC side power flow since the storage suffered from lower input voltage magnitude. On the other hand, the converter is required to work as buck converter during reverse power flow. So the converter must be having bidirectional power flow capability because the need to charge and discharge the coil. The bi-directional Z-source inverter is a new topology, which provides the circuit with bi-directional power flow capacity. This inverter can overcome the limitations of the basic Z-source inverter and be used as an interface between energy storage and utility. A novel modified space vector pulse width modulation (SVPWM) algorithm for bi-directional Z-source inverter is developed in this work, which improves the voltage gain during the boost mode. In the proposed modified SVPWM, four shoot-through states are assigned to each phase within zero state. So zero voltage time period is diminished for generating a shoot-through time, and active states are unchanged. Using MATLAB, the models of the bi-directional Z-source inverter based SMES is established, and the simulation tests are performed to evaluate the system performance.

• Periodical: Applied Mechanics and Materials (Volume 787)
• Pages: 823-827
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.787.823
• Online since: August 2015
• Authors: U. Shajith Ali*
• Keywords: Bi-Directional Z-Source Inverter, Energy Storage Systems, Space Vector PWM

References

[1] P. F. Ribeiro, B. K. Johnson, M.L. Crow, A. Arsoy, Y. Liu, Energy storage systems for advanced power applications, Proceedings of the IEEE. 89 (2001) 1744-1756.

DOI: 10.1109/5.975900

[2] W. V. Hassenzahl, Superconducting magnetic energy storage, IEEE Transactions on Magnetics. 25 (1989) 750–758.

DOI: 10.1109/20.92399

[3] Information on http: /www. lowcarbonfutures. org.

[4] M. Hasan Ali, Bin Wu, R. A. Dougal, An Overview of SMES Applications in Power and Energy Systems, IEEE Transactions on Sustainable Energy. 1 (2010) 38-47.

DOI: 10.1109/tste.2010.2044901

[5] L. Chen, Y. Liu, A. B. Arsoy, P. F. Ribeiro, Detailed modeling of superconducting magnetic energy storage (SMES) system, IEEE Transactions on Power Delivery. 21 (2006) 699-710.

DOI: 10.1109/tpwrd.2005.864075

[6] Jacek Rabkowski, The bidirectional Z-source inverter for energy storage applications, In Proceedings of European Conference on Power Electronics and Applications. (2007) 1-10.

DOI: 10.1109/epe.2007.4417265

[7] Haiping Xu, Z. P. Fang, Lihua Chen, Xuhui Wen, Analysis and Design of Bi-directional Z-source Inverter for Electrical Vehicles, In Proceedings of 23rd Annual IEEE Applied Power Electronics Conference and Exposition. (2008) 1252 – 1257.

DOI: 10.1109/apec.2008.4522883

[8] Jacek Rabkowski, Roman Barlik, Mietek Nowak, Pulse Width Modulation for Bidirectional/High-Performance Z-source Inverter, In Proceedings of IEEE Power Electronics Specialists Conference. (2008) 2750-2756.

DOI: 10.1109/pesc.2008.4592361

[9] S. R. Bowes, Y. S. Lai, The relationship between space-vector modulation and regular-sampled PWM, IEEE Transactions on Power Electronics. 14 (1997) 670–679.

DOI: 10.1109/41.633469

[10] U. Shajith Ali, V. Kamaraj, A Novel Modified Space Vector Pulse Width Modulation Technique for High Performance Z-Source Inverter, International Review of Electrical Engineering. 6 (2011) 618-623.

[11] U. Shajith Ali, V. Kamaraj, A modified space vector PWM for bi-directional z-source inverter, In Proceedings of International Conference on Emerging Trends in Electrical and Computer Technology. (2011) 342-345.

DOI: 10.1109/icetect.2011.5760140
