Independent Control of Force & Displacement Using Shape Memory Alloy Tactile Display

Abstract:

This paper proposes one of the possible techniques for interacting for shape memory alloy (SMA) actuator based tactile display, which can act as demonstrator devices. This work is focused on developing a model of a pair of antagonistic high strain SMA tension actuators with independent control of force and displacement. The technology employed utilizes two Flexinol 100 micron heat actuated wires of Titanium-Nickel (NiTi) shape-memory alloy which contract when heated under pre-stress and produces up to 5% strain recovery. This phenomenon, which provides a unique mechanism for actuation, is associated with the unique interaction between the martensite and austenite crystal structures of the SMA. Physical measurements of the behaviour of the actuator elements were performed using a laser displacement sensor to verify the fidelity of response to software commands, and to measure step response to pulse-width modulated (PWM) current control at different frequencies and duty cycles. Results yielded high accuracy across a wide range of frequencies and duty cycles, proving the SMA actuation technique has potential to present and convey useful tactile information of surface deformation for virtual environment applications.

• Periodical: Applied Mechanics and Materials (Volumes 789-790)
• Pages: 972-981
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.789-790.972
• Online since: September 2015
• Authors: Hussein Mohammed Alalem*
• Keywords: Austenite, Displacement, Force, Martensite, PWM, SMA, Tactile Display

References

[1] H.M. Alalem: Convective Heat Transfer Model on Shape Memory Alloy (SMA) Actuator, Proceedings of the WASET International Conference on Control, Automation, Robotics and Vision, DETC 2009 – 86536, Bangkok (2009).

[2] Dynalloy: Technical Characteristics of FLEXINOL Actuator Wires, Inc, USA (1993).

[3] K. Ikuta: Micro/Miniature Shape Memory Alloy Actuator, IEEE (1990).

[4] I. Kao: Stiffness Control and Calibration of Robotic and Human Hands and Fingers, IEEE (1994).

[5] M. Es-Souni, H.F. Brandies: On the transformation behaviour, mechanical properties and biocompatibility of two NiTi-based shape memory alloys NiTi42 and NiTi42Cu7, vol. 22, no. 15, pp.2153-2161(9) Elsevier Science (2001).

DOI: 10.1016/s0142-9612(00)00406-3

[6] V. Hayward: Design and Comparison of High Strain Shape Memory Alloy Actuators, Proceedings of IEEE International Conference on Robotics and Automation, New Mexico (1997).

DOI: 10.1109/robot.1997.620048

[7] P.M. Taylor, R.I. Davidson, I.P. Shutt, J.D. Ngu and H.M. Allam: Prototype Interactive Tactile Array For C.A. D, in Conf. Rec. 2004 IEEE Int. Conf. Advanced Research in Virtual and Rapid Prototyping, Portugal (2003).

[8] Information on http: /newton. ex. ac. uk/medphys/pages/array1/html.

[9] C. Hasser: Preliminary Evaluation of a Shape Memory Alloy Tactile Feedback Display, Advances in Robotics, Mechatronics, and Haptic Interfaces DSC-Vol. 49, ASME Winter Meeting, ASME, , pp.73-80, New York (1993).

[10] K. Suzuki: High-Density Tactile Sensor Arrays, Advanced Robotics, Vol. 7, No. 3 (1990), pp.283-287.

[11] P. Taylor, A. Moser and A. Creed: A Sixty-Four Element Tactile Display using Shape Memory Alloy Wires, Displays, Vol. 18 (1998), pp.163-168.

DOI: 10.1016/s0141-9382(98)00017-1

[12] W.J. Peine, P.S. Wellman and R.D. Howe: Temporal Bandwidth Requirements for Tactile Shape Displays, Proceedings of the IMECE Haptics Symposium, Dallas, TX (1997).

DOI: 10.1115/imece1997-0384

[13] G. Burdea: Force and Touch Feedback for Virtual Reality, John Wiley & Sons, Inc (1996).

[14] H.M. Allam: Single Element Based Tactile Display, in Conf. Rec. IEEE Int. Conf. Mechatronics, 7803-8599-3/04, Istanbul, Turkey (2004).

[15] Micro-Epsilon: Non-Contact Optical Displacement Measuring System optoNCDT 1605, Instruction Manual, Micro-Epsilon Messtechnik Germany.

[16] CCS: PCB, PCM and PCW PIC C Compiler, Reference Manual, Custom Computer Services, Inc, USA (1999).

[17] N. Gardner: An introduction to programming the Microchip PIC in C, Bluebird Electronics, UK.

[18] Microchip: Microchip Data Book, Micro-chip Technology Inc, USA (1994).

[19] R. Andrew: Robot Tactile Sensing, Prentice Hall of Australia Pty Ltd (1990).
