Mechanical Properties and Corrosion Resistance of Friction Stir Welded Dissimilar Aluminum Alloys 2219 to 5083

Abstract:

In this paper, 6 mm thickness dissimilar aluminium alloys of 5083 (H321) and 2219 (O) butt joints were fabricated successfully by friction stir welding process. The quality joints were obtained for the welding parameters of 35 mm/min and 650 rpm with the shoulder diameter to pin diameter ratio as 3. Macrostructure study shows that the interface between the weld nugget and TMAZ is smooth and clear with a flow arm extending towards the top surface of the weld in the 2219 side. The boundary on the 5083 side between the weld nugget and the TMAZ was irregular. The obtained joint efficiency is around 92.57% based on the UTS of the softer material (AA2219). The tensile test results showed that the specimens failed in the heat affected zone of the softer base material 2219. The hardness values in the stirred zone are higher than the softer base material of alloy 2219. The friction stir welded dissimilar joint 2219-5083 exhibited better general corrosion characteristics than the 2219-2219 weld and 2219 base material.

• Periodical: Applied Mechanics and Materials (Volumes 813-814)
• Pages: 203-207
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.813-814.203
• Online since: November 2015
• Authors: M. Koilraj*, A. Sathesh Kumar, D.L. Belgin Paul, S.R. Koteswara Rao
• Keywords: Corrosion, Dissimilar Aluminium Alloys, Friction Stir Welding, Mechanical Property

References

[1] Yan Yong, Zhang Da-tong, Qiu Cheng Zhan, Dissimilar friction stir welding between 5052 aluminum alloy and AZ31 magnesium alloy, Transactions of Nonferrous Metals Society of China. 20 (2010) s619 - s623.

DOI: 10.1016/s1003-6326(10)60550-x

[2] S. K. Park, S. T. Hong, J. K. Park, K. Y. Park, Y. J. Kwon, H. J. Son, The effect of material locations on the properties of friction stir welding joints of dissimilar aluminium alloys, Science and Technology of Welding and Joining. 15 (2010).

DOI: 10.1179/136217110x12714217309696

[3] C.W. Tan, Z.G. Jiang, L.Q. Li, Y.B. Chen, X.Y. Chen, Microstructural evolution and mechanical properties of dissimilar Al–Cu joints produced by friction stir welding, Materials and Design. 51 (2013) 466–473.

DOI: 10.1016/j.matdes.2013.04.056

[4] Huijie Liu, Huijie Zhang, Qing Pan, Lei Yu, Effect of friction stir welding parameters on microstructural characteristics and mechanical properties of 2219-T6 aluminum alloy joints, Int. J Mater Form. 5 (2012) 235-242.

DOI: 10.1007/s12289-011-1048-5

[5] J.F. Guo , H.C. Chen, C.N. Sun, G. Bi, Z. Sun, J. Wei, Friction stir welding of dissimilar materials between AA6061 and AA7075 Al alloys effects of process parameters, Materials and Design. 56 (2014) 185–192.

DOI: 10.1016/j.matdes.2013.10.082

[6] Y. S. Sato, H. Kokawa, M. Enmoto, S. Jogan, Microstrucrual evolution of 6063 aluminium during friction stir welding, Metallurgical and Materials Transactions A. 30 (1999) 2429-2437.

DOI: 10.1007/s11661-999-0251-1

[7] M. W. Mahoney, C. G. Rhodes, J. G. Flintoff, R. A. Spurling, W. H. Bingel, Properties of friction stir welded 7075 & 651 aluminium, Metallurgical and Materials Transactions A. 29 (1998) 1955-(1964).

DOI: 10.1007/s11661-998-0021-5

[8] Alireza Masoudian, Arvin Tahaei, Atefeh Shakiba, Fariborz Sharifianjazi, Jamshid Aghazadeh Mohandesi, Microstructure and mechanical properties of friction stir weld of dissimilar AZ31-O magnesium alloy to 6061-T6 aluminum alloy, Transactions of Nonferrous Metals Society of China. 24 (2014).

DOI: 10.1016/s1003-6326(14)63194-0

[9] R. S. Mishra, Z. Y. Ma, Friction stir welding and processing, Materials Science and Engineering R. 50 (2005) 1-8.

[10] R. Nandan, T. Deb Roy, H.K.D.H. Bhadeshia, Recent advances in friction stir welding process, weldment structure and properties, Progress in Materials Science. 53 (2008) 980-1023.

DOI: 10.1016/j.pmatsci.2008.05.001

[11] Yong Zhao, Zhengping Lu, Keng Yan, Linzhao Huang, Microstructural characterizations and mechanical properties in underwater friction stir welding of aluminum and magnesium dissimilar alloys, Materials & Design. 65 (2015) 675-681.

DOI: 10.1016/j.matdes.2014.09.046

[12] Long Wan, Yongxian Huang, Weiqiang Guo, Shixiong Lv, Jicai Feng, Mechanical Properties and Microstructure of 6082-T6 Aluminum Alloy Joints by Self-support Friction Stir Welding, Journal of Materials Science & Technology. 30 (2014) 1243-1250.

DOI: 10.1016/j.jmst.2014.04.009
