Mechanical and Morphological Studies of Al6061-Gr-SiC Hybrid Metal Matrix Composites

Abstract:

Abstract. In recent years, Aluminium alloy based metal matrix composites (MMC) are gaining wide spread acceptance in several aerospace and automobile applications. These composites possess excellent wear resistance in addition to other superior mechanical properties such as strength, modulus and hardness when compared with conventional alloys. The hybrid composites are new generation of composites containing more than one type, shape or sizes of reinforcements giving superior combined properties of reinforcements and the matrix. In the present work, Al6061 has been used as matrix material and the reinforcing materials selected were SiC and Graphite particulates of 10 to 30µm size. Composites Al6061-Gr (2- 8 wt. %), Al6061-SiC (2 -10wt. %) and Hybrid composites with Al6061 matrix alloy containing 3wt% graphite and varying composition of 2-10wt% SiCp were prepared by stir casting technique. The cast matrix alloy and its composites have been subjected to solutionizing treatment at a temperature of 530 ± 20C for 6 hours, followed by ageing at a temperature of 175 ± 20C for 6 hours. The mechanical properties of as cast and T6 heat treated composites have been evaluated as per ASTM standards and compared. Addition of Graphite particulates into the Al6061 matrix improved the strength and ductility of the composites. Significant improvement in tensile strength and hardness was noticed as the wt. % of SiCp increases in Al6061-SiC composites. Addition of Graphite into Al6061-SiC further improved the strength and ductility of hybrid composites. The heat treatment process had the profound effect in improving the mechanical properties of the studied composites. The microstructural studies revealed the uniform distribution of SiC and Gr particles in the matrix system.

• Periodical: Applied Mechanics and Materials (Volumes 813-814)
• Pages: 195-202
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.813-814.195
• Online since: November 2015
• Authors: T. Lokesh, U.S. Mallikarjun
• Keywords: Al6061, Graphite, Mechanical Properties, Silicon Carbide (SiC), Stir Casting

References

[1] M K Surappa, Aluminium matrix composites: Challenges and Opportunities, Sadana Vol. 28, Parts 1&2, pp.319-334, (2003).

[2] Clyne T. W, Withers P J, An introducation to metal matrix comosites, Cambridge university press, (1993).

[3] Torralba J M , Da Costa CE, Velasco F, P/M, Aluminum matrix composites : An overview, J. Mat. Process. Tech., Vol. 1-2, pp.203-206, (2003).

[4] Alexander Evans , Christopher San Marchi , Andreas Mortensen , Metal matrix composites in industry and a survey, Kluwer Academic Press , (2003).

[5] K G Satyanarayana, R M Pillai and B C Pai, Developments in Science and Technology of Cast Aluminium Matrix Composites – An overview, TMS Annual Meeting and Exhibition, 2006, USA, pp.51-61.

[6] B C Pai , R M Pillai and K G Satyanarayana, Prospects for graphite aluminium composites in Engineering industries, Ind. J of Engg. and Material Sciences, Vol. 1, pp.279-285, (1994).

[7] Prashanth S N, Madev Nagaral and V Auradi, Preparation and Evaluation of Mechanical and Wear properties of Al6061 reinforced with Graphite and SiC particulate MMCs, In. J Mech. Engg and Rob. Reas., Vol. 1, (2012).

[8] Veeresh kumar G B, C S P Rao, Selvaraj N and Bhagyashekar M. S, Stuidies on Al6061-SiC and Al7075-Al2O3 Metal Matrix Composites, J. Min. and Mat. Char. Engg., Vol. 9, pp.47-59, (2009).

[9] Himanshu Kala, K.K.S. Mer and Sandeep Kumar, A Review on Mechanical and Tribological behaviors of Stir Cast Aluminum Matrix Composites, Procedia Material Science, Vol. 6, pp.1951-1960, (2014).

DOI: 10.1016/j.mspro.2014.07.229

[10] Dora siva prasad, chintada shoba and Nallur Ramanaiah, Investigations on Mechanical properties of Aluminium Hybrid composites, JMR & T, Vol. 3(1), 2014, pp.79-85.

[11] Charles S , Arunachalam, V. P, Property analysis and Mathematical Modelling of Machining Properties of Aluminum alloy hybrid ( Al-alloy-SiC-Flyash) Composites Produced by liquid Metallurgy and Powder Metallurgy Techniques, Ind.J. Engg. and Material Sciences, Issue 11, pp.473-480, (2004).

[12] M. Vamsi Krishna and Anthony. M. Xavior, An Investigation on the Mechanical Properties of Hybrid Metal Matrix Composites, Proc. Engg., Vol. 97, pp.918-924, (2014).

DOI: 10.1016/j.proeng.2014.12.367

[13] C.B. Lin, R.J. Chang, and W.P. Weng, A study on process and tribological behavior of Al alloy/ Gr. (p) composite, WEAR, Vol. 217, pp.167-174, (1998).

DOI: 10.1016/s0043-1648(98)00192-6

[14] Callister W.D. Jr, Material Science and Engineering - An Introduction, 2nd edition, John Wiley, New York, (1991).

[15] Swamy ARK, Ramesh A, Veeresh kumar G B and Prakash J N, Effect of particulate reinforcements on the mechanical properties of Al6061-WC and Al6061-Gr MMCs, J. Min. and Mat. Char. and Engg., Vol. 10, pp.1141-1152, (2011).

DOI: 10.4236/jmmce.2011.1012087

[16] C S Ramesh and Mir Safiulla, Wear Behaviour of Hot extruded Al6061 based Composites, WEAR, Vol. 263, pp.629-635, (2007).

DOI: 10.1016/j.wear.2007.01.088

[17] A Ramesh, J N Prakash, A S Shivashankare gowda and Sonnappa Appaiah, Comparision of the Mechanical Properties of Al-Gr Metal Matrix Composites, J. Min. and Mat. Char. & Engg., Vol. 2, pp.93-106, (2009).

[18] SONG Min, Effects of Volume fraction of SiC particles on Mechanical properties of SiC/Al composites, Transactions of Nonferrous Metals Society of China, Vol. 19, pp.1400-1404, (2009).

DOI: 10.1016/s1003-6326(09)60040-6
