Performance Test of Cryogenically Treated and Coated Tungsten Carbide Cutting Inserts

Abstract:

Production cost is dependent on the life of the Tool. Because of enormous heat generation during the material removal process, life of the tool decreases. Tool life will be enhanced by cryogenic treatment which minimises the temperature at tool tip interface. Taguchi technique was employed to get optimum number of experiments for turning white cast iron after the cryogenic treatment and before cryogenic treatment. The correlation between four main factors such as speed, feed, depth of cut, tool condition and responses such as surface roughness, tool tip temperature were analysed. Mathematical model was formulated for tool tip temperature, and surface roughness. The error for the mathematically formulated model was observed to be less than 5%.The present work indicates that cryogenically treated tool have better surface finish . From the anova analysis it is inferred that tool tip temperature and surface roughness substantially reduced while using cryogenically treated tool. It was observed that cutting forces was more influenced by cutting speed of the tool followed by tool condition. Hardness of the tool insert showed improvement because of coatings.

• Periodical: Applied Mechanics and Materials (Volumes 813-814)
• Pages: 575-580
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.813-814.575
• Online since: November 2015
• Authors: Y.P. Deepthi*, K. Prakash Marimuthu, K. Raghavendra Ravi Kiran
• Keywords: Cryogenic Treatment, Multi-Layer Coating, Orthogonal Array, Regression Model

References

[1] E B Soraka, S A Klimenko, and M YU Kopeikina, Ensuring the Adhesion and Cohesion strength of PVD (TiAl)N and TiN coatings, , (2011).

DOI: 10.1134/s0036029511040203

[2] W Grzesik, Z Zalisz, S Krol, Tribological behaviour of TiAlN coated carbides in dry sliding tests, Journal of AMME, vol17, july-Aug (2006).

[3] T V Sreeramareddy et al., Machinability of C45 steel with deep cryogenic treated tungsten carbide cutting tool inserts, Int. journal of refractory metals and hard materials 27(2009), 181-185.

DOI: 10.1016/j.ijrmhm.2008.04.007

[4] M N Islam et al., An investigation of surface finish in dry turning, Proceedings of the world congress on Engineering vol I, jul 6th -8th (2011).

[5] Simranpreet singh gill, Rupinder singh, Harpreet singh and jagdev singh, Wear behavior of cryogenically treated tungsten carbide inserts under dry and wet turning conditions, Int. journal of machine tools and manufacture. vol 49, issues 3-4, March 2009, pp.256-260.

DOI: 10.1016/j.ijmachtools.2008.11.001

[6] A Y L Yong, K H W seah and M Rahman, Performance of cryogenically treated tungsten carbide tools in milling operations, , int J Adv. Manuf. Technol. 32(2007), pp.638-643.

DOI: 10.1007/s00170-005-0379-0

[7] K H W Seah, M Rahman and K H Yong, Performance evaluation of cryogenically treated tungsten carbide cutting tool inserts, Proc. Inst. Mech. Eng. Part B:J. Eng. Manuf. 217.

DOI: 10.1243/095440503762502260

[8] Harold A. Stewart , Cryogenic Treatment of tungsten carbide reduce tool wear when machining of medium density fibreboard, Forest product journal, vol. -52, page 53 -56 , (2004).

[9] Gallagher, A.H., Agosti, C. D, Roth, J.T. (2005), Effect of cryogenic treatments on tungsten carbide tool life: microstructural analysis, Trans. North Am. Manuf. Res. Inst. SME, Vol. 33, p.153–160.

[10] M Sh Migranov and A Sh Makhmutova, Wear resistance and tribological properties of cutting tool coatings, Russian engineering research, 2007 vol 11, p.777-780K H W seah, A Y L yong and M rahman, performance evaluation of cryogenically treated tungsten carbide cutting tool inserts, Proc. Inst. Mech. Eng. Part B:J. Eng. Manuf. 217(2003).

DOI: 10.3103/s1068798x07110093

[11] Y P Deepthi et al., Effect of double tempering after cryogenic treatment on coated inserts, Proceeding of national conference on Emerging Research and Advances in Mechanical Sciences, 23rd march 2012, VEC, Coimbatore.

[12] Stratton PF, optimizing nanocarbide precipitation in tool steels, . Material Science and Engineering , vol 449-451, pages 809-812, (2007).

DOI: 10.1016/j.msea.2006.01.162

[13] Huang JY, Zhu TY, Liao XZ, Beyerlein IJ, Bourke MA, Mitchell TE(2003), Microstructure of cryogenic treated M2 tool steel, Material Science and Engineering, vol 339, pages 241-244.

DOI: 10.1016/s0921-5093(02)00165-x
