Numerical Simulation of Al 6062 Alloy Deformation Behavior Using Equal Channel Angular Extrusion Process with Different Die Angles

Abstract:

The equal channel angular extrusion (ECAE) is one of the most important methods used for bulk metal forming. In which die angles are the most importent parameter. This paper attempts to determine the effect of different die angles during ECAE process for 6062 aluminum alloy deformation. Numerical simulations are performed for ECAE process on cylindrical billet of 6062 aluminum alloy at a constant frictional coefficient (μ) of 0.08 and punch speed of 15 mm/sec. Die has made with inner corner angles of (φ) =105^°, 115^°, 125^°and 135^° by fixing the outer corner angle (ψ) of 6^°, punch is designed with a radii (R) of 4.75mm and height of 50mm. From the simulation results, tha data has been obtained in the form of load stroke behavior, and energy consumend during the punch stoke. It is observed that the maximum load and more energy consumption during the process is noted for lower angle.

• Periodical: Applied Mechanics and Materials (Volumes 813-814)
• Pages: 557-562
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.813-814.557
• Online since: November 2015
• Authors: Aitha Lavanya, Perumalla Janaki Ramulu*, G. Sreekanth Kumar, P. Ramya Sree, Sirish Battacharya, Daya Sindhu Guptha
• Keywords: Angular Dies, Deformation Behavior, Equal Channel Angular Extrusion (ECAE), Process Parameters

References

[1] P. Eslami, A. Karimi Taheri, An investigation on diffusion bonding of aluminum to copper using equal channel angular extrusion process, Mat. Lett. 65 (2011), 1862–1864.

DOI: 10.1016/j.matlet.2011.03.053

[2] K. O. Sanusi, O. D. Makinde, G. J. Oliver, Equal channel angular pressing technique for the formation of ultra-fine grained structures, South Afri. J. of Sci. 108. 9-10 (2012), 1-7.

DOI: 10.4102/sajs.v108i9/10.212

[3] F. Al-Mufadi, F. Djavanroodi, Finite Element Modeling and Mechanical Properties of Aluminum Proceed by Equal Channel Angular Pressing Process, Int. J. of Mech., Aero., Ind. and Mechatr. Engg. 8 (2014), 1411-1416.

[4] R. S. Sharma, R. K. Pal, A. Sahai, A. Dayal, S. Gupta, H. Anand, K. Hans Raj, Finite Element Modeling of ECAP of Al7075 specimen with different die geometries, Int. J. of Adv. Manuf. Sys. 15 (2014), 111-121.

[5] R. Thiyagarajan, A. Gopinath, Enhancement of Mechanical Properties of AA 6351 Using Equal Channel Angular Extrusion (ECAE), Mat. Scie. and Metall. Engg. 2 (2) (2014) 26-30.

[6] F. Djavanroodi, B. Omranpour, M. Ebrahimin, M. Sedighi, Designing of ECAP parameters based on strain distribution uniformity, Pro. in Nat. Sci.: Mat. Inter. 22 (2012) 452-460.

DOI: 10.1016/j.pnsc.2012.08.001

[7] B. Tolaminejad, A. Karimi Taheri, M. Shahmiri, H. Arabi, Development of Crystallographic Texture and Grain Refinement in the Aluminum Layer of CU-AL-CU Tri-Layer Composite Deformed by Equal Channel Angular Extrusion, Int J. of Mod. Phy. 5 (2012).

DOI: 10.1142/s201019451200219x

[8] Mohamed Ibrahim Abd El Aal, Ho Yong Um, Eun Yoo Yoon, Hyoung Seop Kim, Microstructure evolution and mechanical properties of pure aluminum deformed by equal channel angular pressing and direct extrusion in one step through an integrated die, Materls Scie, and Engg : A, 625 (2015).

DOI: 10.1016/j.msea.2014.11.089

[9] J. Nemati, G. H. Majzoobi, S. Sulaiman, B. T. H. T. Baharudin, M. A. Azmah Hanim, Effect of equal channel angular extrusion on Al-6063 bending fatigue characteristics, Int. Jour. of Mine., Met. and Mat., 22 (2015), 395-404.

DOI: 10.1007/s12613-015-1085-z
