Analysis and Processing of Index Tests Results at Double-Adjust Hydraulic Turbines with a Computer-Aided Design Software

Abstract:

The paper presents a method developed and used by the CCHAPT researchers for the graphic plotting of the index tests results for hydraulic turbines, the comparison of the efficiency curves resulted from testing to those obtained by the model transposition [1] i.e. the determination and comparison of the existing combinatory cam with that obtained from tests.The method presented in the paper was born from the need for processing and presenting the results of index tests within the shortest delay and eliminating the errors that might occur in the results plotting.

• Periodical: Applied Mechanics and Materials (Volume 823)
• Pages: 396-401
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.823.396
• Online since: January 2016
• Authors: Adrian Cuzmoş*, Dorian Nedelcu, Constantin Viorel Câmpian, Cristian Fănică, Ana Maria Budai
• Keywords: B-Spline, Combinatory Cam, Hydraulic Efficiency, Hydraulic Turbine, Index Tests

References

[1] ***** Determination of the prototype performance from model acceptance tests of hydraulic machines with consideration of scale effects, Standard international IEC 995, Publication (1991).

DOI: 10.3403/00416402

[2] I.A. Winter, Improved Type of Flow Meter for Hydraulic Turbines, Proceedings of the ASCE, (1933).

[3] N. I. Zubarev, Index method for determination of turbine efficiency during full-scale tests, Gidrotekhnicheskoe Stroitel'stvo, 4, (2010), 27 – 29.

[4] Z.G. Yan, L.J. Zhou, Z.W. Wang, Turbine efficiency test on a large hydraulic turbine unit, Science China Press and Springer-Verlag Berlin Heidelberg, (2012).

[5] ***** Hydraulic turbines, storage pumps and pump-turbines – Model acceptance tests, International Standard IEC 60193, Second edition, 1999-11, International Electrotechnical Commission.

DOI: 10.3403/30131984u

[6] C.V. Câmpian, D. Nedelcu, V. Barbu, C. Dumbravă, A. Cuzmoş, V. Suciu, Index tests performed on hydro unit no. 6 at CHE Iron Gates I before and after refurbishment, CCHAPT Technical Report no. U-02-400-23, August, (2012).

[7] C.V. Câmpian, Index tests performed on hydro unit no. 6 at CHE Iron Gates I before refurbishment, Annals of the University Eftimie Murgu, of Reşiţa, Year IV, no. 1, ISSN 1453-7394, Reşiţa, (1999), 63-72.

[8] R.H. Bartels, J.C. Beatty, B.A. Barsky, An Introduction to Splines for Use in Computer Graphics & Geometric Modeling, Morgan Kaufmann Publ., Los Altos CA 94022, (1987).

[9] C. de Boor, A Practical Guide to Splines, (Revised Edition), Springer-Verlag, New York, (2001).
