Rotor Vibration under the Coupled Effects of Mass Unbalance and Asymmetric Bearings

Abstract:

Large unbalance in rotor-dynamic systems is typically responsible for high energy vibrations and the consequent decrease in machine life. This paper presents an analytical model developed using Lagrangian mechanics and partial differential equations (PDEs) for the purpose of early fault-detection in rotor-bearing systems. The model was validated through a Fortran based program, RDA99 developed by Adams (2010), by successfully quantifying the single-peak unbalance response of the simple 8 DOF and 12 DOF rotor-bearing mass stations over two cases. Case I uses bearings with symmetric stiffness and damping matrix. The critical speed for Case I occurred at 1690 rpm and orbital shapes of each mass station was found to be circular with forward-whirl orbits. In Case II asymmetrical bearing stiffness and damping coefficient matrices demonstrate an anisotropic system. Critical speed occurred at 1655 rpm and rotor, bearing and pedestal orbits were seen to be elliptical and changing with shaft speed. Both cases demonstrated a significant shaft bending contribution to the disk displacement.

You might also be interested in these eBooks

Advances of Computational Mechanics in Australia

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 846)

Pages:

199-204

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.846.199

Citation:

Cite this paper

Online since:

July 2016

Authors:

Joseph Patrick Spagnol*, Helen Wu

Keywords:

Anisotropic Bearings, Flexible Shaft, Rotor Dynamics, Unbalance, Whirling Orbits

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Z. Kıral, H. Karagülle, Vibration analysis of rolling element bearings with various defects under the action of an unbalanced force, Mechanical Systems and Signal Processing, 20 (2006) 1967-(1991).

DOI: 10.1016/j.ymssp.2005.05.001

Google Scholar

[2] J. -J. Sinou, F. Thouverez, Experimental Study of a Flexible Rotor and Its Dependency on the Rolling-Bearing Temperature, International Journal of Rotating Machinery, (2006) 1-8.

DOI: 10.1155/ijrm/2006/38595

Google Scholar

[3] A. Bouzidane, M. Thomas, An electrorheological hydrostatic journal bearing for controlling rotor vibration, Computers & Structures, 86 (2008) 463-472.

DOI: 10.1016/j.compstruc.2007.02.006

Google Scholar

[4] S. -C. Hsieh, J. -H. Chen, A. -C. Lee, A modified transfer matrix method for the coupled lateral and torsional vibrations of asymmetric rotor-bearing systems, Journal of Sound and Vibration, 312 (2008) 563-571.

DOI: 10.1016/j.jsv.2008.01.006

Google Scholar

[5] M.L. Adams, Rotating Machinery Vibration: From Analysis To Troubleshooting, Second Edition, CRC Press, (2010).

Google Scholar
