Periodic and Chaotic Response of a Macro-Scale Tuning Fork Gyroscope

Abstract:

In this paper, the dynamic behaviour of a macro-scale tuning fork gyroscope is presented. The gyroscope consists of two inverted pendulums on a suspension mass. The suspension mass is subjected to force excitation generated by an electromagnetic shaker. The dynamics of the shaker are included in the analysis. It is shown that the system is a parametrically excited system. Parametric excitation can lead to vibration in the horizontal motion of the suspension mass, when the two pendulums are in phase. The problem is particularly interesting for energy harvesting. Due to the interaction between the system’s degrees of freedom, the energy is transferred from vertical (base excitation) to horizontal direction. Initial parametric studies are carried out to analyse the dynamic behaviour of the system by varying the initial conditions, base excitation frequency and amplitude. It is demonstrated that under certain parameters the system can exhibit complex dynamic behaviour such as chaotic motion.

• Periodical: Applied Mechanics and Materials (Volume 849)
• Pages: 84-94
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.849.84
• Online since: August 2016
• Authors: M. Ghandchi Tehrani*, Marcos Silveira, José Manoel Balthazar
• Keywords: Nonlinear Dynamics, Parametric Excitation, Tuning Fork Gyroscope

References

[1] M. Ghandchi Tehrani and M. Kalkowski, Active control of parametrically excited systems, Journal of Intelligent Material Systems and Structures, 2015, 1-13.

DOI: 10.1177/1045389x15588625

[2] Y. Lee, A study of parametric excitation applied to a MEMS tuning fork gyroscope, Phd dissertation , Faculty of the Graduate School – University of Missouri – Columbia, (2007).

DOI: 10.32469/10355/4697

[3] Y. Lee, P. Frank , Z. C. Feng , Nonlinear complex response of a parametrically excited tuning fork, Mechanical Systems and Signal Processing, 22(5), 2008, 1146-1156.

DOI: 10.1016/j.ymssp.2007.11.015

[4] J. Warminski, J.M. Balthazar, Vibration of a parametrically and self-excited system with ideal and non-ideal energy source, RBCM-Journal of the Brazilian Society, mechanical Sciences, 25(4), 2003, 413-420.

DOI: 10.1590/s1678-58782003000400014

[5] J.M. Balthazar J.M., J.L. P Felix., Revisited nonlinear non-ideal vibration. In: Vibration Problems ICOVP (Supplement), Technical University of Liberec, Prague, Czech Public, pp.84-89, (2011).

[6] X. Xu, E. Pavlovskaia, M. Wiercigroch., F. Romeo, S. Lenci, Dynamic interactions between parametric pendulum and electro-dynamical shaker – ZAMM, Journal of Applied Mathematics and Mechanics, 87, 2, 172-186, (2007).

DOI: 10.1002/zamm.200610311

[7] X. Xu, M. Wiercigroch, M. P. Cartmell, Rotating orbits of a parametrically-excited pendulum – Science Direct – Chaos, Solitons and Fractals, 1538-1548pp., June, (2004).

DOI: 10.1016/s0960-0779(04)00430-8

[8] K. Kecik and J. Warminski, Chaos in mechanical pendulum-like system near parametric resonance, IUTAM Symposium on 50 years of chaos: Applied and Theoretical, 5(2012), 249-258.

DOI: 10.1016/j.piutam.2012.06.034

[9] A.M. Tusset, V. Piccirillo, A. M. Bueno, J.M. Balthazar, D. Sado, J. L. P. Felix, R.M.L.R.F. Brasil, Chaos control and sensitivity analysis of a double pendulum arm excited by an rLC circuit based nonlinear shaker, Journal of vibration and control, 2015, 1-17.

DOI: 10.1177/1077546314564782

[10] G. A. Gottwald and I. Melbourne. A new test for chaos in deterministic systems. Proc. Roy. Soc. A 460 (2004) 603–61.
