Vibration Analysis of Mixed Flow Pump Impeller Blade Designed Using Mean Stream Line Method

Abstract:

Mixed flow pumps applications have been exploited in a large number of diversified fields of engineering. They find applications as an important component in waste water treatment systems, power stations, irrigation systems etc. User requirements make these pumps to work very close to the functioning requirements and therefore under these conditions the vibrations are bound to occur in different moving components of the pump. It would be difficult to analyse the pump vibrations, considering the pump as a single system. Analysing vibrations in different moving components of the pump will not only be easier but also will aid in reducing the vibrations at the microscopic level. As a subject of the present paper, the mixed flow pump impeller blade has been designed using sparingly used yet accurate mean stream line theory. Modal analysis of the pump blade has been carried out at different modes of frequency. Total deformation for different modes of frequencies has also been determined. Stainless steel has been used as the construction material of the impeller blade.

• Periodical: Applied Mechanics and Materials (Volume 852)
• Pages: 476-482
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.852.476
• Online since: September 2016
• Authors: Divya Zindani, Apurba Kumar Roy, Kaushik Kumar*
• Keywords: Impeller Blade, Mean Stream Line Theory, Mixed Flow Pump, Modal Analysis, Total Deformation

References

[1] G. F Wislicensus, The Design of mixed flow pumps, (1965).

[2] D. J Myles, A design method for mixed flow fans and pumps, Report No. 117, National Engineering. Laboratory. (1965).

[3] A.J., Stepanoff Centrifugal and Axial flow pumps, John Wiley and sons 2nd Edition, New York. (1957).

[4] B. Neumann, The interaction Between Geometry and Performance of a centrifugal Pump, Mechanical Engineering Publications, London. (1991).

[5] V.K. Gahlot and A. Nyiri, Impeller Pumps, Theory and design,M.A.C. T, Bhopal, (1993).

[6] M. Zangeneh, A. Goto, T. Takemura, Suppression of secondary flows in a mixed flow pump impeller by application of three-dimensional inverse design method: Part 1 – design and numerical validation, ASME Trans J Turbomach. 118 (1996). 536–43.

DOI: 10.1115/1.2836700

[7] J.Z. Xu., C.W. Gu, A numerical procedure of three-dimensional design problem in turbo machinery, ASME Trans J Turbomach. 114 (1992) 548–82.

[8] J.E. Borges, A three-dimensional inverse method for turbo machinery: Part-1Theory, ASME Trans J Turbo. 112 (1994) 346–54.

[9] G Peng, S. Cao, M. Ishizuka, S. Hayama, Design optimization of axial flow hydraulic turbine runner: Part I – an improved Q3D inverse method, International journal for numerical methods in fluids. 39 (2002) 517–31.

DOI: 10.1002/fld.342

[10] J.S. Anagnostopoulos. A fast numerical method for flow analysis and blade design in centrifugal pump impellers, Comput Fluids. 38 (2009) 284–289.

DOI: 10.1016/j.compfluid.2008.02.010

[11] S. Srivastava, A. K Roy, K. Kumar, Design of a Mixed Flow Pump Impeller Blade and its Validation Using Stress Analysis, Procedia Mater Sci. 6 (2014) 417–24.

DOI: 10.1016/j.mspro.2014.07.053

[12] S.C. Mustata, D. Dracea, A.S. Tronac, N. Sarbu, E. Constantin, Diagnosis and Vibration Diminishing in Pump Operation, Procedia Engineering . 100 ( 2015 ) 970 – 976.

DOI: 10.1016/j.proeng.2015.01.456

[13] J. Grosel, W. Pakos, W. Sawicki, Experimental Measurements as the Basis for Determination of the Source of Pumps' Excessive Vibration, Theoretical Foundation of Civil Engineering. 111 (2015) 269-276.

DOI: 10.1016/j.proeng.2015.07.088

[14] K. Fetyan, D. El_Gazzar, Effect of motor vibration problem on the power quality of water pumping stations, Water Science. 28: 1 (2014) 31-41.

DOI: 10.1016/j.wsj.2014.05.001

[15] S. Kaviani, M. Bahrami, A.M. Esfahani, A modeling and vibration analysis of a piezoelectric micro-pump diaphragm, Comptes Rendus Mécanique. 342 (12) 692-699.

DOI: 10.1016/j.crme.2014.06.005

[16] W. Li, H. Lu, Y. Zhang, C. Zhu, X. Lu, Z. Shuai, Vibration analysis of three-screw pumps under pressure loads and rotor contact forces, Journal of Sound and Vibration. 360 (2016) 74-96.

DOI: 10.1016/j.jsv.2015.09.013

[17] X. Wang, T.C. Li, L.H. Zhao, Vibration analysis of large bulb tubular pump house under pressure pulsations, Water Science and Engineering. 2: 1 (2009) 86-94.
