Prediction of Workpiece Elastic Deformation Using FEM Based Contact Analysis

Abstract:

The proper selection of fixtures and its locations is necessary to avoid the dimensional and form inaccuracies that are developed due to elastic deformation of the workpiece during machining. It is necessary to predict the elastic deformation with higher precision in order to eliminate the above inaccuracies during the design of fixtures. In the present work, a Finite Element Method (FEM) based 3D contact analysis has been proposed to evaluate the elastic deformation of the workpiece under the influence of fixtures and machining forces. In the proposed model, workpiece has been considered as flexible body and fixture elements (locators and clamps) as rigid bodies. A new concept of pre-stressed harmonic analysis has been introduced in order to simulate the machining forces. The contact area of the locators has been considered using contact elements and the clamping forces as point forces. The model for the analysis is developed in ANSYS environment with suitable elements. The effect of material removal has also been considered in the analysis in view of obtaining more accurate and realistic results. The deformation of the workpiece has been predicted for a particular location of clamps, locators and machining forces and presented. It is possible to optimize the location of clamps and locators under the influence of machining forces, the above analysis is suggested.

• Periodical: Applied Mechanics and Materials (Volume 852)
• Pages: 498-503
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.852.498
• Online since: September 2016
• Authors: F. Michael Thomas Rex*, D. Ravindran, N. Lenin
• Keywords: Contact Analysis, Elastic Deformation, Finite Element Method (FEM), Fixture Design

References

[1] G. Prabhaharan, K.P. Padmanaban, R. Krishnakumar, Machining fixture layout optimization using FEM and evolutionary techniques, International Journal of Advanced Manufacturing Technology, 32 (2007) 1090-1103.

DOI: 10.1007/s00170-006-0441-6

[2] B. Li, S.N. Melkote, Improved workpiece location accuracy through fixture layout Optimization, International Journal of Machine Tools and Manufacture, 39 (1999) 871–883.

DOI: 10.1016/s0890-6955(98)00072-8

[3] N. Kaya, Machining fixture locating and clamping position optimization using Genetic Algorithms, Computers in Industry, 57 (2006) 112-120.

DOI: 10.1016/j.compind.2005.05.001

[4] K. Kulankara, S. Satyanarayana, S.N. Melkote, Iterative fixture layout and clamping force optimization using the genetic algorithm, ASME Journal of Manufacturing Science and Engineering, 124 (2002) 119-125.

DOI: 10.1115/1.1414127

[5] W. Chen, L. Ni, J. Xue, Deformation control through fixture layout design and clamping force optimization, International Journal Of Advanced Manufacturing Technology, 38 (2008) 860-867.

DOI: 10.1007/s00170-007-1153-2

[6] N. Kaya, F. Ozturk, The Application of chip removal and frictional contact analysis for workpiece–fixture layout verification, International journal of advanced manufacturing technology, 21 (2003) 411-419.

DOI: 10.1007/s001700300048

[7] X. Wan, Y. Zhang, X. Huang, Investigation of influence of fixture layout on dynamic response of thin-wall multi-framed work-piece in machining, International Journal of Machine Tools and Manufacture, 75 (2013) 87-99.

DOI: 10.1016/j.ijmachtools.2013.09.008

[8] X. Wan, Y. Zhang, A novel approach to fixture layout optimization on maximizing dynamic machinability, International Journal of Machine Tools and Manufacture, 70 (2013) 32-44.

DOI: 10.1016/j.ijmachtools.2013.03.007

[9] F.M.T. Rex, D. Ravindran, An integrated approach for optimal fixture layout design, Proc IMechE, Part B: Journal of Engineering Manufacture, Epub ahead of print 2 July 2015. DOI: 10. 1177/0954405415590991.

[10] B. Li, S.N. Melkote, Fixture Clamping Force Optimisation and its Impact on Workpiece Location Accuracy, International Journal of Advanced Manufacturing Technology, 17 (2001) 104-113.

DOI: 10.1007/s001700170198
