Autonomous External Glass Cleaning Robot

Abstract:

This paper deals with an autonomous external glass cleaning robot that can perform the operation by ensuring proper adhesion to the glass as well as movement along the entire window without colliding with the window pane or any other obstacle. The concept used in this work to actuate the robot is pneumatics wherein a pneumatic cylinder is coupled with a linear channel made up of stainless steel. It has a guide and a block which are connected through a chain and sprocket. The block can move along the guide. The piston of the cylinder is coupled with the block while the cylinder barrel is coupled with the guide. Adhesion of the robot to the glass is ensured using the vacuum technology. Four suction cups are used to make the robot adhered to the glass. Two channels are placed at right angle with each other, one for horizontal motion and one for vertical motion. Stepwise movement of the robot is achieved by individual control of suction cups. This is done using the software Arduino and Arduino UNO R3 microcontroller. Ultrasonic sensors are used to measure the dimension of the window pane as well as detect the obstacle/edge of the window. The cylinders and vacuum generators are actuated using solenoid DCV’s. As the robot moves, a rotating disk located at the bottom of the robot has a cleaning brush/sponge attached to it which cleans the glass as the robot and hence the entire glass surface is covered and cleaning operation is performed autonomously. The advantage of this robot is its simple design and its feasibility. The fact that we are able to successfully move the robot on a vertical glass frame without damaging it allows us to use it for several other applications too such as inspection.

• Periodical: Applied Mechanics and Materials (Volume 852)
• Pages: 757-762
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.852.757
• Online since: September 2016
• Authors: R. Ranjani*, M. Nandhini, C. Arun Prakash
• Keywords: Solenoid Valves, Vacuum Technology

References

[1] Houxiang Zhang, Jianwei zhang, Guanghua zong, Effective pneumatic scheme and control strategy of a climbing robot for a class wall cleaning on High-rise Building, International journal of advanced Robotic system, vol. 3, No. 2, (2006).

DOI: 10.5772/5738

[2] Miyake, T.; Ishihara, H. (2003). Mechanisms and Basic Properties of Window Cleaning Robot, Proceedings of the 2003 IEEE/ASME International Conference on Advanced Intelligent Mechatronics, pp.1372-1377.

DOI: 10.1109/aim.2003.1225543

[3] Houxiang zhang, Rong Liu, Guanghua zong, Jianwei zhang, A Novel Automous climbing robot for cleaning an Elliptic Half-shell, Proceeding of Mobile Robitics towards New application, December (2006).

DOI: 10.1109/icma.2005.1626880

[4] Zhang, H.; Zhang, J.; Zong, G. (2004). Realization of a Service Climbing Robot for Glass-wall Mechatronics and Automation, August 26-31, Chengdu, China, pp.101-106.

[5] W. Wang, G. Zong, Controlling and Sensing Strategy for Window Cleaning Robot, Hydraulics & Pneumatics, No. 1, p.4–7, (2001).

[6] K. T uru, and K. Yoneda, Window Cleaning Robot With Magnetic Synchronous Drive, Journal of the Robotics Society of Japan, Vol. 25, No. 5, pp.738-744, (2007).

DOI: 10.7210/jrsj.25.738

[7] E. Gambao, and M. Hernando. Control System for a Semi-automatic Façade Cleaning Robot. D p to. De Automática, Universidad Politécnica de Madrid, (2006).

[8] T.C. Apostolescu, N. Alexandrescu, C. Udrea, D. Duminic ă: Original solution for an autonomous mobile robot with vertical displacement, in Bulletin of the Polytechnic Institute of Jassy, Fascicle 3, Volume LIV (LVIII), Section Machine Construction, 2008, pp.87-92.

[9] G. W. Aslam, and M. Dean, Design, Fabrication and Testing of a Miniature Wall Climbing robot. E. Lansing, MI 48824, USA : Michigan State University, June, (2007).

[10] R. D. Schraft, et al.; Service Robots, AK Peters, Ltd, (2000).

[11] Zhu, J.; Sun D. and Tso, S. K. (2003). Application of a service climbing robot with motion planning and visual sensing . Journal of Robotic Systems , Vol. 20, No. 4., pp.189-199.

DOI: 10.1002/rob.10080

[12] V. Gradetsky, M. Rachkov, S. Kalinichenko, E. Semenov Service robot for cleaning of vertical surfaces, IARP International Advanced Robotics Programme service and personal robots: technologies and applications , Genova, Italy, 23-24 Oct. (1997).
