The Effect of Base Pressure on Crystal Structure and Microstructure of CrN Thin Film Deposited by Reactive Magnetron Sputtering

Abstract:

The CrN thin films were deposited using reactive magnetron sputtering by varying base pressure to investigate the crystal structure, microstructure and composition of thin film. In this work, the films properties were characterized by XRD, FE-SEM and EDX techniques. The crystal structures were obtained the cubic of CrN with the crystal size between 23.23 – 28.25 nm and lattice parameters a = b = c = 4.142 - 4.160 Å. The XRD results indicated that the growth of preferred orientation was changed from (200) to (111) plane with increased the base pressure. The surface morphology of CrN thin films did not affected from base pressure. The thickness of CrN thin films which obtained from cross section analysis was decreased from 1788 to 1745 nm by varying the base pressure. The columnar pattern acccompany with the dense structure were investigated from the cross-section analysis. The Cr composition was substantly decreased whereas theN₂ composition were increased which observed from EDX technique.

• Periodical: Applied Mechanics and Materials (Volume 866)
• Pages: 301-304
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.866.301
• Online since: June 2017
• Authors: Adisorn Buranawong*, Nirun Witit-Anun
• Keywords: Base Pressure, CrN, Reactive Magnetron Sputtering

References

[1] A. Conde, C. Navas, A.B. Cristóbal, J. Housden ,J. de Damborene, Characterisation of corrosion and wear behaviour of nanoscaled e-beam PVD CrN coatings, Surf. Coat. Technol. 201 (2006) 2690-2695.

DOI: 10.1016/j.surfcoat.2006.05.013

[2] S. Mahieu, D. Depla, R. De Gryse, Characterization of the hardness and the substrate fluxes during reactive magnetron sputtering of TiN, Surf. Coat. Technol. 202 (2008) 2314-2318.

DOI: 10.1016/j.surfcoat.2007.09.002

[3] M. Novaković, M. Popović, N. Bibić, Ion-beam irradiation effects on reactively sputtered CrN thin films, Nucl. Instr. Meth. Phys. Res. B. 268 (2010) 2883-2887.

DOI: 10.1016/j.nimb.2010.03.027

[4] K. Valleti, C. Rejin, S.V. Joshi, Factors influencing properties of CrN thin films grown by cylindrical cathodic arc physical vapor deposition on HSS substrates, Mater. Sci. Eng. A. 545 (2012) 155-161.

DOI: 10.1016/j.msea.2012.02.098

[5] J. Xu, H. Umehara, I. Kojima, Effect of deposition parameters on composition, structures, density and topography of CrN films deposited by r. f. magnetron sputtering, Appl. Surf. Sci. 201 (2002) 208-218.

DOI: 10.1016/s0169-4332(02)00942-x

[6] H. Zhang, S. Duo, X. Xu, T. Li, Effect of N2 flow rate on structure and mechanical properties of CrN coating prepared by closed field unbalance magnetron sputtering, Key. Eng. Mater. 591 (2014) 95-98.

DOI: 10.4028/www.scientific.net/kem.591.95

[7] J.E. Greene, J. -E. Sundgren, L. Hultman, I. Petrov, D.B. Bergstrom, Development of Preferred Orientation in Polycrystalline TiN Layers Grown by Ultra-High-Vacuum Reactive Magnetron Sputtering, Appl. Phys. Letters. 67, (1995) 2928-2930.

DOI: 10.1063/1.114845

[8] Smith, DL. Thin-Film Deposition: Principle And Practice. New york: McGrawHill; (1995).

[9] D Mergel, D Buschendorf, S Eggert, R Grammes, B Samset, Density and refractive index of TiO2 films prepared by reactive evaporation, Thin Solid Films. 371 (2000) 218-224.

DOI: 10.1016/s0040-6090(00)01015-4
