A Study on Temperature Properties of Different Types of Fixed Resistor

Abstract:

This paper studies the relationship between the value of temperature variation and the resistance value of each type of general resistors as well as also determines the temperature coefficient value of each resistor type. All obtained results will be compared to build a guideline for selecting the resistor to apply in any applications accurately and properly. Each type of 1 k-ohm resistor that has different power is used to study its properties and is controlled its temperature variation to be in range of 20 to 30 degree Celsius. An experimental setup to control the temperature variation of the resistors in this paper is that the resistors are put into an oil bath controlled its temperature after that measuring the changed resistance value of the resistors following oil temperature in the bath. The experimental result demonstrates that the temperature variation affects to change the resistance value of Carbon Film type the most but affects to change the resistance value of Wire Wound type with low power the least.

• Periodical: Applied Mechanics and Materials (Volume 866)
• Pages: 392-397
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.866.392
• Online since: June 2017
• Authors: Nattapong Phanthuna*, Chaiwat Jassadajin
• Keywords: Divider Resistor, Resistance Measurement, Temperature Coefficient

References

[1] B. Schumacher and P. Warnecke, Transport behavior of commercially available 100 /spl Omega/ standard resistors, CPEM 2000 Conference Digest, 2000, pp.486-487.

DOI: 10.1109/cpem.2000.851095

[2] B.J. Pritchard and G. W. Small., Temperature Coefficient Variation in Heat Treated Evanohm and Their Effect on the Transient Behavior of the NML 1 Ω Resistors, IEEE Trans. Instrum. Meas., vol. 42(2), 1993, pp.557-561.

DOI: 10.1109/19.278625

[3] WU. Jian, LI. Zheng-kun, and CHEN. Le, Research on Analysis and Measurement Method for Thermal Resistance of Precision Resistor, ICIEA. 2014 IEEE Conference, 2014, pp.1510-1514.

[4] J.H. Dellinger, The Temperature Coefficient of Resistance of Copper, Bulletin of the Bureau of Standards, vol. 7, no. 1, pp.88-90.

[5] T. Sorsdal, Determination of Standard Resistor Temperature Coefficients, CPEM 2002 Conference Digest, 2002, pp.46-47.

DOI: 10.1109/cpem.2002.1034712

[6] G.R. Jones and R.E. Elmquist, Characterization of loading effects in precision 1Ω Resistor, Conf. Digest of CPEM 2008, Broomfield: 2008, 392-393.

[7] H. Sasaki, H. Nishinaka, and K. Shida, Automated measurement system for 1-Ω Omega standard resistor using a modified Wheatstone bridge, Conf. Digest of CPEM 1990, 122-123.

DOI: 10.1109/cpem.1990.109952

[8] J. Lan, Z. Zhang, Z. Li, Q. He, B. Han, S. Li, and G. Wang, High Precision Measurement of the Load Effect of the Resistor, Conf. Digest of CPEM 2008, Washington D. C : 2012, 380-381.

DOI: 10.1109/cpem.2012.6250962
