Analysis and Optimum Structure of Deformation Coordination of Crankshaft-Bearing System

Abstract:

Aiming at realizing the coordination deformation of crankshaft-bearing system for engine, the equation of coordination deformation for crankshaft-bearing system was derived based on the theory of elasticity. According to the hydrodynamic lubrication theory, the mathematical model was established to analyze the bearing characteristics; the displacement of each bearing in the vertical direction was calculated by combined solution of the two parts above. The sum of squared differences of displacements was evaluated as evaluation standard of coordination deformation for crankshaft-bearing system. Then bearing clearances were chosen as optimized variables of crankshaft coordination deformation for the optimization. The crankshaft-bearing system of one type of engine was optimized for the coordination deformation. The results indicate that the optimization scheme of crankshaft-bearing system can make a significant improvement to coordination deformation and provide reference for the design of the engine.

• Periodical: Applied Mechanics and Materials (Volume 868)
• Pages: 224-229
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.868.224
• Online since: July 2017
• Authors: Xiao Mei You, Xiao Tian Shi*, Xing Guo Ma, Guo Ying Chai, Gui Chun Yang
• Keywords: Coordinative Deformation, Crankshaft, Main Bearing

References

[1] Bao Rong. Efficient dynamics analysis of large-deformation flexible beams by using the absolute nodal coordinate transfer matrix method, J. Multibody Syst Dyn, 2014, 32(4): 535–549.

DOI: 10.1007/s11044-013-9402-7

[2] Ihn Sung Cho, Jae Youn, Jung. The friction characteristics of the journal bearing in a reciprocating compressor for refrigeration and air conditioning systems, J. Journal of Mechanical Science and Technology, 2014, 28(4): 1473-1480.

DOI: 10.1007/s12206-014-0132-4

[3] J. CHOI, KIM, RHIM, J.H. CHOI. Numerical modeling of journal bearing considering both elastohydrodynamic lubrication and multi-flexible-body dynamics, J. International Journal of Automotive Technology, 2012, 13(2): 255−261.

DOI: 10.1007/s12239-012-0022-7

[4] Jorwekar, Pavan P, Birari, Yogesh V, Nadgoudav, Mayur M. Cylinder. Head Gasket Contact Pressure Simulation for a Hermetic Compressor. International Compressor Engineering Conference at Purdue, C. 2006. 1795.

[5] Masanori Takahashi, Ryoji Isarai, Hiroki Hara. Measurement of Piston Using the New Digital Telemeter, C. SAE Paper 2013-01-1708. 2013: 577-586.

DOI: 10.4271/2013-01-1708

[6] Kazunori. M, Shinichi. K, et al. Reduction of piston system friction by apply a bore circularity machining technology to the cylinder block, C. SAE 2005-01-1656. (2005).

[7] Franz Maassen, Franz Koch. Analytical and Empirical Methods for Optimization of Cylinder Liner Bore Distortion, C. SAE 2001-01-0569. (2001).

DOI: 10.4271/2001-01-0569

[8] F. Koch, P. Decker. Cylinder Liner Deformation Analysis-Measurements and Calculations, C. SAE Paper1998-980567. (1998).

[9] Lawrence E. Bird, Robert M. Gartside. Measurement of Bore Distortion in a Firing Engine, C. SAE Paper 2002-01-0485. (2002).

DOI: 10.4271/2002-01-0485

[10] N. Antoni, F. Gaisne. Analytical modeling for static stress analysis of pin-loaded lugs with bush fitting, J. Applied Mathematical Modelling, 2011, 35(1): 1-21.

DOI: 10.1016/j.apm.2010.05.002

[11] ZHENG Guang-ze, YUAN Lin. Research on piston slap considering coupled vibration of hydrodynamic lubrication and dynamics of internal combustion engine, J. JOURNAL OF VIBRATION AND SHOCK, 2015, 34(20): 92-97.

[12] ZHANG Xiao-qi, Wu Jian, et al. Research on piston slap considering coupled vibration of hydrodynamic lubrication and dynamics of internal combustion engine, J. mechanical science and technology for aerospace engineering, 2015, 01(07): 32-36.
