Effect of Dimensionless Numbers on Air Core Diameter of Pressure-Swirl Atomizer

Abstract:

Air core is an important parameter in pressure swirl atomizer since formation of air core determines the thickness of the discharged liquid sheet and the effective flow area of nozzle discharge. This consequently will affect the coefficient of discharge and the spray angle. This study conducted for the investigation of the relation between dimensionless numbers on the air core diameter. Dimensionless numbers are helpful aid for the quantification of independent parameters involving atomizer design and operating conditions simultaneously. Reynolds number, Re and orifice-to-swirl chamber diameter ratio, N are the dimensionless numbers selected for this study. Despite of the availability of study on the effect of dimensionless numbers on air core diameter, more study requires especially for smaller N. An experimental test-rig was constructed to conduct the performance test of the atomizer. Acquired images were analyzed using image-processing software. It was found that N has more significant effect on the change of air core diameter compared to Re. However, it is observed that at Re = 40000, N = 0.07 produces almost similar air core diameter with N = 0.25 at Re < 20000. In contrast, with N = 0.5, air core diameter produces are larger even at Re < 20000. Hence, it can be concluded that both Re and N are important parameters in characterizing the air core diameter in pressure-swirl atomizer.

• Periodical: Applied Mechanics and Materials (Volume 899)
• Pages: 22-28
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.899.22
• Online since: June 2020
• Authors: Zulkifli Abdul Ghaffar*, Salmiah Kasolang, Ahmad Hussein Abdul Hamid, Mohd Syazwan Firdaus Mat Rashid
• Keywords: Air Core Diameter, Direct Photography, Orifice-to-Swirl Chamber Diameter Ratio, Pressure-Swirl Atomizer, Reynolds Number

References

[1] A. Ibrahim, Comprehensive study of internal flow field and linear and nonlinear instability of an annular liquid sheet emanating from an atomizer,, (2006).

[2] Z. Liu, Y. Huang, and L. Sun, Studies on air core size in a simplex pressure-swirl atomizer,, Int. J. Hydrogen Energy, vol. 42, no. 29, p.18649–18657, (2017).

DOI: 10.1016/j.ijhydene.2017.04.188

[3] M. Malý, L. Janá, J. Jedelský, J. Sláma, M. Sapík, and G. Wigley, Internal flow and air core dynamics in Simplex and Spill-return pressure-swirl atomizers,, Int. J. Heat Mass Transf., vol. 123, p.805–814, (2018).

DOI: 10.4995/ilass2017.2017.4995

[4] E. J. Lee, S. Y. Oh, H. Y. Kim, S. C. James, and S. S. Yoon, Measuring air core characteristics of a pressure-swirl atomizer via a transparent acrylic nozzle at various Reynolds numbers,, Exp. Therm. Fluid Sci., vol. 34, no. 8, p.1475–1483, (2010).

DOI: 10.1016/j.expthermflusci.2010.07.010

[5] J. J. Chinn, Dimensional Analysis and the Buckingham-Π Theorem Applied to the Inviscid Swirl Atomizer Governing Equations,, in Proceedings of the 21st ILASS-Europe Meeting, (2007).

[6] E. Giffen and A. Muraszew, The atomization of liquid fuels. Lodon: Chapman & Hall, (1953).

[7] M. R. Halder, S. K. Dash, and S. K. Som, Initiation of air core in a simplex nozzle and the effects of operating and geometrical parameters on its shape and size,, Exp. Therm. Fluid Sci., vol. 26, no. 8, p.871–878, (2002).

DOI: 10.1016/s0894-1777(02)00153-x

[8] M. S. F. M. Rashid, A. H. A. Hamid, O. C. Sheng, and Z. A. Ghaffar, An experimental investigation on the effect of various swirl atomizer orifice geometries on the air core diameter,, Appl. Mech. Mater., vol. 225, (2012).

DOI: 10.4028/www.scientific.net/amm.225.32

[9] A. H. Lefebvre and M. Suyari, Film thickness measurements in a simplex swirl atomizer,, J. Propuls. Power, vol. 2, no. 6, p.528–533, (1986).

DOI: 10.2514/3.22937

[10] Hedland, MR Flow Transmitter Installations and Programming Instructions,, vol. HLIT 306, (2008).

[11] A. H. A. Hamid, S. Kasolang, and Z. A. Ghaffar, On the Effect of Central Jet in Solid Cone Pressure- Swirl Atomizers,, J. Mech. Eng., vol. SI 5, no. 3, p.260–271, (2018).

[12] A. Datta and S. K. Som, Numerical prediction of air core diameter, coefficient of discharge and spray cone angle of a swirl spray pressure nozzle,, Int. J. heat fluid flow, vol. 21, no. 4, p.412–419, (2000).

DOI: 10.1016/s0142-727x(00)00003-5

[13] J. J. Chinn, The numerics of the swirl atomizer,, in ILASS 2008, Sep. 8-10, 2008, Como Lake, Italy, 2008, p.1–7.
