Research on the Interference Correction in the CNC Incremental Forming

Abstract:

Aiming at the problem of global interference correction that the extrusion tool is entirely contained within the workpiece in 5-axis CNC incremental forming, a method that can avoid interference by correcting only once based on STL (StereoLithography) model is proposed in this paper. The interference critical point is found by using the plane which is paralleled to the extrusion tool and the Z-axis to cut the extrusion tool and the workpiece model, and then the interference correction angle is calculated through the interference cirtical point. The case study shows that this method is simple, effective and it can correct interference only by one step.

• Periodical: Advanced Materials Research (Volumes 1004-1005)
• Pages: 1084-1088
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1004-1005.1084
• Online since: August 2014
• Authors: Hu Zhu*, Zhang Wei, Jin Ju, Yi Bo Liu
• Keywords: Correction, Incremental Forming, Interference Detection, NC Incremental Forming

References

[1] M. Tisza: Journal of Achievements in Materials and Manufacturing Engineering Vol. 55(2012), pp.113-119.

[2] J.H. Mo, F. Han: China Mechanical Engineering Vol. 19(2008), pp.491-497, in Chinese.

[3] Jeswiet J, Micari F, Hirt G, et al: Annals of the CIRP-Manufacturing Technology Vol. 54(2005), pp.623-649.

[4] H. Zhu, J.H. Fu: Chinese Journal of Lasers Vol. 36(2009), pp.3313-3317, in Chinese.

[5] H. Zhu, X.G. Yang: Journal of Mechanical Engineering Vol. 50(2014), pp.3313-3317, in Chinese.

[6] H.B. Yuan: Computer Aided Design and Manufacture Tutorials (National Defence Industry Press, Bei Jing 2007), in Chinese.
