The Design of PLC Control of Multi Degree of Freedom Landscape Showcase

Abstract:

In order to make the different angles of the viewers get the best visual effects, the paper proposed a lift tilt rotary landscape showcase which can show all kinds with multi-degree of freedom. Showcase uses the electric motor to drive and PLC applications in the system which can be programmed to control various types of mechanical components, to achieve the function of lifting and descending of 4 position, 8 position, and 12 position, horizontal lift and rotating in 360-degree. The test and operation results demonstrate that the showcase meets the specific functional demand of design.

• Periodical: Advanced Materials Research (Volumes 1030-1032)
• Pages: 1554-1557
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1030-1032.1554
• Online since: September 2014
• Authors: An Liu*, Jing Tao Wei
• Keywords: Electric Control System, Mechanical Transmission, Multi-Degree of Freedom, PLC
