The Roller Speed Control of High Voltage Electrostatic Separator Based on PLC

Abstract:

The main aim of this paper is improve the high voltage electrostatic separation efficiency of roll-type electrostatic separator. To this end, a method of controlling the roller to obtain the best rotate speed was introduced. Experiments of system design were performed on 315-2DP type Programmable Logic Controller (PLC) produced by Siemens, E6B2 - CWZ6C encoder provided by Omron and MM440 converter obtained from Siemens. According to the nature differences of the separation particles, presetting the roller rotation speed in the upper machine. Then it is downloaded to the PLC. Through the tail encoder of the motor to receive the signals, calculating the roller speed and feedback to the PLC to control the converter, then formed a closed-loop control system of the motor speed.

• Periodical: Advanced Materials Research (Volume 1037)
• Pages: 240-243
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1037.240
• Online since: October 2014
• Authors: Zi Sheng Zhang*, Jin Cui, Qing Yang, Shi Ming Ren, Bo Sun
• Keywords: Control System, Electrostatic Separation, PLC, Roller Rotation Speed

References

[1] Zi Sheng Zhang, Peng Bo Ge, Xiao Dong Shi, Bo Feng Liu, Zhi Qiang Liu. The Control System of High Voltage Electrostatic Precipitator Based on FPGA[J]. Advanced Materials Research, 2013, 823: 528-531.

DOI: 10.4028/www.scientific.net/amr.823.528

[2] A. Samuila, A. Urs, A. Iuga, R. Morar, F. Aman, L. Dascalescu, Optimization of corona electrode position in roll-type electrostatic separators, IEEE Trans. Ind. Appl. 41 (2005) 527–534.

DOI: 10.1109/tia.2005.844859

[3] Zi Sheng Zhang, Xiao Jun Feng, Jian Ping Bai , Jian Rong Chai, Peng Li, Zhi Qiang Liu, Qing Li. The System Analysis of The Insulating Power Supply in High Voltage Electric Field[J]. Journal of Hebei University, 2008, 28 (5): 486-489.

DOI: 10.1109/icmlc.2008.4620721

[4] Zi Sheng Zhang, Bo Feng Liu, Shu Qing Guo, Deng Yuan Song, Zhan You Wang. Application of Programmable Logic Controller in Sewage Treatment [J]. Advanced Materials Research, 2014, 910: 332-335.

DOI: 10.4028/www.scientific.net/amr.910.332

[5] L. Dascalescu, R. Morar, A. Iuga, A. Samuila, V. Neamtu, I. Suarasan, Charging of particulates in the corona field of roll-type electroseparators,J. Phys. D: Appl. Phys. 27 (1994) 1242–1251.

DOI: 10.1088/0022-3727/27/6/023

[6] Zi Sheng Zhang, Dao Liu, Bo Feng Liu, Xiao Dong Shi, Zhi Qiang Liu. Temperature of Transformer Controller Based On TMS320C6713 [J]. Advanced Materials Research, 2013, 823: 528-531.

DOI: 10.4028/www.scientific.net/amr.823.555

[7] S. Zhang, E. Forssberg, Optimization of electrodynamic separation for metals recovery from electronic scrap, Resources, Conserv. Recycl. 22 (1998)143–162.

DOI: 10.1016/s0921-3449(98)00004-4
