Automated Microinjection System Design and Experiments Based on Hybrid-Driven Micro-Robot

Abstract:

In order to resolve the operation difficulty, high cost problems of traditional manual cell microinjection, a low-cost microinjection system based on hybrid-driven micro-robot is presented. System is mainly composed of microscope, 3-DOF(degrees of freedom) micro-robot, signal generator and power amplifier. Firstly, we describe the automated microinjection system. Secondly, we analyze the motion performance of the robot in the horizontal and vertical direction. The single step resolution is less than 5um each step working at a frequency more than 200Hz. Maximum range of vertical motion is 5mm and minimum resolution ups to 2um. Finally, shrimp egg microinjection experiment is conducted using our system. The experimental result shows that this proposed scheme is simple, reproducible and can achieve microinjection success rate of 88%.

• Periodical: Advanced Materials Research (Volumes 1049-1050)
• Pages: 1116-1121
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1049-1050.1116
• Online since: October 2014
• Authors: Chuan Bo Qin*, Lian Fang Tian, Qi Liang Du, Qin Zhang
• Keywords: Microinjection, Micro-Robot, Piezoelectric Ceramic (PZT), Voice Coil Motor

References

[1] Liu X Y, Lu Z, Sun Y. Orientation control of biological cells under inverted microscopy [J]. IEEE/ASME Transactions on Mechatronics, 2011, 16(5): 918-924.

DOI: 10.1109/tmech.2010.2056380

[2] Zhang Y, Tan K K, Huang S. Vision-servo system for automated cell injection [J]. Industrial Electronics, IEEE Transactions on, 2009, 56(1): 231-238.

DOI: 10.1109/tie.2008.925771

[3] Sun M Z. Visual Feedback and Localization of Micro-Manipulation System Oriented Complex Task[D]. Nankai University, (2009).

[4] Tian G, Hou L, Zhang W. Mechanical analysis and experimental research on adjusting technology for cellular position and attitude in micro-injection[J]. China Mechanical Engineering, 2009, 20 (04): 500 - 503.

[5] Chen H I, Shih M C. Visual Control of an Automatic Manipulation System by Microscope and Pneumatic Actuator[J]. Automation Science and Engineering, IEEE Transactions on, 2013, 10(1): 215-218.

DOI: 10.1109/tase.2012.2205239

[6] Yu B J, Yang Z G, Zhou G L. Control system for cell injection device based on TMS320DM642 and S3C2410[J]. Optics and Precision Engineering, 2008, 16(8): 1500 - 1507.

[7] Fuchiwaki O. Insect-sized holonomic robots for precise, omnidirectional, and flexible microscopic processing: Identification, design, development, and basic experiments [J]. Precision Engineering, 2013, 37(1): 88-106.

DOI: 10.1016/j.precisioneng.2012.07.004

[8] Zhang Q, Wu Z, Du Q. Structure of a hybrid driven miniature robot: China, 201010271587. 1[P]. 2011-01-19.
